Float Level Sensor 5CFS-0825-1A
|
|
|
|
|
Max. Contact Rating |
10 W |
50 W |
||
Max. Switching Voltage |
100 VDC |
200 VDC |
||
Max. Switching Current |
0.5 A |
1.5 A |
||
Min. Breakdown Voltage |
220 VDC |
300 VDC |
||
Max. Carry Current |
1.0 A |
3.0 A |
||
Max. Initial Contact Resistance |
100 mΩ |
|||
Temperature Rating |
-10 ~ +80 |
|||
Float Ball Material |
PP |
|||
Float Body Material |
PP+GF |
|||
Screw Nut Material |
PP+GF |
|||
E-Ring Material |
PP |
|||
Dimension unit: mm
