Home > Electrical & Electronics > Connector & Terminals > Wire to Wire Connector > RJ45 1*2port Modular PCB 10p Connector/Jack
RJ45 1*2port Modular PCB 10p Connector/Jack
US$ 0.142 - 2.2
MOQ: 1500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
CSCE
Model Number:
SC617-5622S-10P-1*2
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Multi-Port 8 Pin Pcb RJ45 ConnectorUS$ 0.16 - 1.85MOQ: 1000 Pieces -
LED Side Entry Multi-ports RJ45 JackUS$ 0.16 - 0.9MOQ: 1000 Pieces
-
Multi-ports RJ45 Pcb With Shield SocketUS$ 0.15 - 0.24MOQ: 2500 Pieces
-
Multi-ports1XN RJ45PCB Jack/connector/socketNegotiableMOQ: 1
-
1*2 PORTS RJ11 PCB JACK/CONNECTOR/SOCKETNegotiableMOQ: 1
Place of Origin
Zhejiang, China
Brand Name
CSCE
Model Number
SC617-5622S-10P-1*2
Type
RJ45
Application
PCB
Gender
Female
Specifications
1. RJ45 PCB Connector with 1*2 port and round pin.2.UL,RoHS,ISO9001-2000
Description:
RJ45 PCB Connector
Number of ports:2
Number of position: 10
Number of contacts: 2,4,6,8 or 10
Electrical:
Rated current: 1.5A
Rated voltage: 125VAC
Insulation resistance: 500MΩmin
Contact resistance: 30MΩmax
Withstanding voltage: 1000VAC RMS, 50 or 60Hz 1 Min
Mechanical:
Insertion force: 2.2kgf max
Retention strength: 7.7kgf min between jack and plug
Durability: 600 mating cycles minimum
Materials:
Housing: ABS resin (UL94V-0), PBT (UL94V-0), PA66 (UL94V-0), and PA46 (UL94V-0)
2. Contact Wire: Diameter 0.45mm phosphor bronze gold plating over
Nickel
3. Shield: 0.20~0.25mm thickness brass with tin plated
4. Gold Plating: Fu",+3u",6u",15u",30u",50u"
