Electrical Insulation/Special Ceramics/Al2O3 Ceramic Thermocouple Tube
*Good thermal conductivity
*Good strength and hardness
*Good resistance to wear and corrosion
*Temperature resistance up to 1800°C
Ceramic furnace tubes, thermocouple protection tubes and insulating rods produced by UNIPRETEC are made of alumina ceramic (Al2O3 > 99%). Alumina ceramic possesses a high melting point, strong hardness, and good chemical stability, making it a good material to withstand high temperature and chemical corrosion. The max. using termperature of these tubes & rods can be up to 1800 °C. They are an excellent choice in furnace and temperature measurement whenever safety and stability are required.
The size of the high temperature ceramic tubes & rods can be customized according to customers' requirement:
- The ceramic furnace tubes can be made from OD 27~120mm and length 100~1750mm.
- Ceramic thermocouple protection are one end closed tubes, standard dimension ranges are OD 5~50mm and length 100~1750 mm.
- Insulating rods & tubes are usually with one bore, two bores and four bores, the dimension ranges are OD 1~12mm and length 100~1800mm.
As a professional company in advanced ceramic industries, UNIPRETEC is manufacturing and supplying high quality and high precision ceramic components for clients from worldwide. Our ceramic products are widely used in various fields of automotive, metallurgy, machinery, electronic & electrical, food, chemical, medical and so on. With experienced engineers and talented workers, we are able to evaluate projects and drawings properly, make valuable suggestion, supply satisfying products. Our materials including:
- Aluminium Oxide ( 95% 96% 99% 99.5% 99.7% Al2O3 )
- Zirconium Oxide ( Yttria stabilized ZrO2 )
- Silicon Nitride ( Gas pressure sintered & Hot pressed Si3N4 )
- Boron Carbide ( B4C )
- Boron Nitride ( Hot pressed BN )
- Machinable Glass Ceramic
Aiming at building long term cooperation relationship with our clients, we set our motto as "Quality First". Far now, our products have been exported to North Amirica, East Europe, West Europe, East Asia, Southeast Asia and get good reputation from our client.
--- Boron Nitride Ceramic Parts --- --- Ceramic Grinding Media --- --- ZrO2 Zirconia Ceramic Parts ---
