DUPLEX STRAINER

DUPLEX STRAINER- DB150 Duplex Strainers

Design Features:

• §  Standard sizes from 6” – 24”.
• §  Available with RF or RT] flanged (ASME B16.5) or Buttweld (ASME B16.9) end connections.
• §  Standard thru bolt cover design.
• §  Custom modifications are available.
• §  May be installed in horizontal pipelines.
• §  Strainers designed to meet the requirements of ASME B31.1, ASME B31.3 and/or ASME Section VIII, Div. I.
• §  Four individual operated butterfly valves are used to divert and isolate flow. Ball, gate and other isolation valve types may be used if requested.
• §  304 SS perforated screens are standard.
• §  Drains and differential connections are standard and are furnished with plug.
• §  Vents and special covers are optional.
