Specifications
Structure combinationUsing three parts combined type cabinets, the upper cabinet(fume cabinet), middle( worktop),
1,Operation table-board,the operation table-board is made off 12.7mm thickness solid stainless physiochemical board, around board is 25.4 board,it can suffer 98% Strong acid and alkali,it also can suffer 1200°C,it can prevent the liquid spare ,the cup should put the right sides.
2,Cabinet,double-edged E1 16mm melamine MDF Board,surroundings take 2mm PVC Seal the border water treatment.
3,lining and guide,double-edged E1 16mm melamine MDF Board,surroundings take 2mm PVC Seal the border water treatment. Spoiler ‘sposition should make sure that all kinds of gas be puss out from the Cabinet.
4,Windows,5mm strong glass with PVC spout and without noise Stepless speed balance farmar design, Windows height can be stopped in any position.
5, fluctuation and adjust the door
1) the 5 mm safety toughened glass, no zone design, can stay balanced in any position.
2) adjust doorknob hand design, accord with human body engineering requirement, in order to be convenient for the user to force pull up and down.
3) adjust the door wide open mouth height 760 mm (including) above
6, lighting: the whole prover lamp holder, anti-corrosion design chimney is enclosed with 220 V, 30 W fluorescent lamp one. Mesa intensity of illumination reached 400 LUX, lamps and lanterns and ballasts do not and ventilation, and the air in contact with easy to change.
7 and accessories
1) faucet: Taiwan a male stand-up ceramic core high quality water, which can adjust the tip of horizontal direction.
2) test tank: use black PP acid and alkali resistance, corrosion cup slots.
8, control panel: set to get an electric shock protection automatic air switch, fan switch, lighting switch, and bring five hole electrical outlet.
Can depend on customer's demand make special size.
Specifications (standard)
Specification |
1200mm L*D*H |
1500mm L*D*H |
1800mm L*D*H |
Outer Size |
1200*850*2350 |
1500*850*2350 |
1800*850*2350 |
Inner Size |
990*750*1205 |
1290*750*1205 |
1590*750*1205 |
Under cabinet size |
1200*650*860 |
1500*650*860 |
1800*650*860 |
Cabinet |
860 |
860 |
860 |
Open door high |
650 |
650 |
650 |
Recommend using surface wind speed |
In the open air inlet position, and 60% of the highly hood use average surface wind speed not less than 0.5 m/s |
||
