high purity Alumina ceramic sleeve/bushing
- 5000 Piece / Pieces per Month
- SHANGHAI
- T/T Credit Card
- Sodium Lauryl Ether Sulphate /SLES 70% for personal care
- Precision Ceramic Chuck Semiconductor Equipment
- Ceramic Tubes with Fine Tube Sizes Available For Customization
- Corrosion Resistant and Insulating Alumina Ceramic Tube
- ST.CERA Customized Precision Zirconia Ceramic tube
- Semiconductor Ceramic Components Ceramic Focusing Rings
Product Details
Place of Origin: | Jiangsu, China | Type: | Ceramic Tubes | Application: | Industrial Ceramic |
Material: | Alumina Ceramic | Brand Name: | EB |
Product Description
Specifications
1.Material:99%Alumina2.Precious dimensions
3.Wear resistance static-proofing
4,Shaped as your designing and requirment
Function:
Alumina ceramic sleeve has the advantages of super hardness,high wear-resisting,good corrosion resistance resistant acid-base, high intensity, high temperature tolerance, high mechanical strength and so on.It widely used in various mechancal field.
Property:
Items | Unit | 95%Al2O3 | 99.5%Al2O3 |
Density | g/cm3 | 3.7 | 3.9 |
Flexural Strength | MPa | 313 | 340 |
Compressive Strength | MPa | 3400 | 3600 |
Modulus of Elasticity | GPa | 350 | 380 |
Impact Resistance | MPa·m1/2 | 4 | 5.1 |
Weibull Modulus | m | 10 | 10 |
Vickers Hardness | HV0.5 | 1800 | 1900 |
Thermal Conductivity | W/mk | 24 | 27 |
Highest Application Temperature | °C | 1600 | 1750 |
Volume Resistivity at 20°C | Ω.cm20 | >1014 | >1014 |
Dielertric strength | KV/mm | 20 | 25 |
Thermal expansion | X10-6/K | 5.0-8.3 | 5.4-8.3 |
1,drying pressing
2,isostatic pressing
3,hot pressing casting
The application of our product:
1, ceramic shaft for aquatic animals equipment filter pump
2, Ceramic plunger for high pressure cleaner.
3,Wearlessness,resistant acid-base and high intensity ceramic assembly apply to petroleum ,chemical and chemical industry.
4,Wearlesness, corrosion resistance, thermostable parts apply to precision machine.
