Specifications
Pneumatic Rock drill1.Air pressure:0.4- 0.63MPa
2.Drill bit dia:34-42mm
3.Usage:mine laneway and blasting holes
The rock drill is a kind of high efficiency air leg rock drill machinery.It is mainly used for diging into mine laneway and blasting holes in all drilling works. It is indispensably importance machine tool in metallurgy, coal, railway, traffic, water conservancy construction and national defence stone project. It is suitable for drilling and blasting under various of rocks at any direction angles. Blast hole dia is 34-42mm, drill hole depth is 5 m This machine may match with Model FT160A short air leg ,This machine has transparent surface of FY200A oil reservoir, easy to observe the oil lever, adjust oil quantity, ensure the well lubricated.
Features
1. Air leg rock drill widely used in coal, metallurgy, railway, transport, water, infrastructure and national defense projects of various levels of rock, tilt, down the hole drilling operations
2. The use of modern design means,performance of each product is optimized.
3. For all operating agencies were arranged according to ergonomic principles, to ensure that the products of high-performance, high efficiency and convenience of operation, security.
4. Quality materials and scientific and forging, all reflect the "quality " content, to ensure that the products of high strength, high wear resistance and impact resistance.
5. CNC machining, Uncase automatic line treatment, given "quality" of the guarantee and the "tough" self-confidence.
6. Computer-controlled drilling machine from the factory run test bed, grasp the dynamic characteristics of each product to avoid the occurrence of human error to ensure that the manufactured products of excellent quality and superior performance.
Specification |
|
Weight |
≈ 26 kg |
Length |
661mm |
Cylinder dia |
80mm |
Piston stroke |
60mm |
Air pressure |
0.4- 0.63MPa |
Impact frequencey |
≥ 37 Hz |
Air consumption |
≤81L/S |
Air pipe (inner dia ) |
25mm |
Water pipe (inner dia ) |
13mm |
Drill bit dia |
34-42mm |
Shank dimensions(hex×length) |
22×108±1mm/ 25×108±1mm |
The function specification that Air pressure is 0.63Mpa | |
FT160B Air leg(short) | |
Length |
1800mm |
Push stroke |
1365mm |
Cylinder dia. |
65mm |
Weight |
≈ 16.9 kg |
FY200A oil reservoir | |
Oil capacity |
200ml |
About our company
Our products are not only popular in China, but also exported to Vietnam, Indonesia, Korea, Turkey, the Philippines, Cambodia, Pakistan, Mongolia etc, gradually increasing the amount of exports and import-export rights. With China's accession to WTO, enterprises will be further developed. We warmly welcome customers to come in various forms of cooperation and seek common development.
