Help CenterQiankun Pneumatic Super Rock Drill YO18
Related Products
Specifications
super Rock drill1.Air pressure:0.4- 0.63MPa
2.Drill bit dia:34-42mm
3.Usage:mine laneway and blasting holes
Rock drill YO18
The rock drill is a kind of high efficiency air leg rock drill machinery.
It is mainly used for diging into mine laneway and blasting holes in all drilling works. It is indispensably importance machine tool in metallurgy, coal, railway, traffic, water conservancy construction and national defence stone project.
It is suitable for drilling and blasting under various of rocks at any direction angles. Blast hole dia is 34-42mm, drill hole depth is 5 m This machine may match with Model FT160A short air leg ,This machine has transparent surface of FY200A oil reservoir, easy to observe the oil lever, adjust oil quantity, ensure the well lubricated.
Specification
Specification |
|
Weight |
≈ 26 kg |
Length |
661mm |
Cylinder dia |
80mm |
Piston stroke |
60mm |
Air pressure |
0.4- 0.63MPa |
Impact frequencey |
≥ 37 Hz |
Air consumption |
≤81L/S |
Air pipe (inner dia ) |
25mm |
Water pipe (inner dia ) |
13mm |
Drill bit dia |
34-42mm |
Shank dimensions(hex×length) |
22×108±1mm/ 25×108±1mm |
The function specification that Air pressure is 0.63Mpa | |
FT160B Air leg(short) | |
Length |
1800mm |
Push stroke |
1365mm |
Cylinder dia. |
65mm |
Weight |
≈ 16.9 kg |
FY200A oil reservoir | |
Oil capacity |
200ml |
Application :
1.widely used in coal, metallurgy, railway, transportion,
2.water conservancy, infrastructure and defense engineering in the level of all kinds of rocks.
Features:
1. Qiankun brand air leg rock drill widely used in coal, metallurgy, railway, transport, water, infrastructure and national defense projects of various levels of rock, tilt, down the hole drilling operations
2. The use of modern design means,performance of each product is optimized.
3. For all operating agencies were arranged according to ergonomic principles, to ensure that the products of high-performance, high efficiency and convenience of operation, security.
4. Quality materials and scientific and forging, all reflect the "quality " content, to ensure that the products of high strength, high wear resistance and impact resistance.
