High Wear Resisitance Alumina/zirconia/silicon Machinable Ceramic Rod

High Wear Resisitance Alumina/zirconia/silicon Machinable Ceramic Rod thumbnail-1
High Wear Resisitance Alumina/zirconia/silicon Machinable Ceramic Rod photo-1
US$ 0.1 - 10 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Type:
Ceramic Rods
Application:
Industrial Ceramic
Contact Supplier Request Quote Chat Now
Suzhou Everbest Engineering Ceramics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Type Ceramic Rods
Application Industrial Ceramic
Material Zirconia Ceramic
Model Number OEM
Brand Name Yongjia

Specifications

Ceramic Rods
1.High insulation
2.high strength,high corrosion resistance
3.high wear resistance
4.manufacturer OEM

Alumina /zirconia/silicon ceramic rod 3mm

high wear resisitance Alumina/zirconia/silicon machinable ceramic rodhigh wear resisitance Alumina/zirconia/silicon machinable ceramic rod



 1,Property

 High insulation, high strength, high corrosion resistance, and high wear resistance.



 Items

Unit

95%Al2O3

99.5%Al2O3

Density

g/cm3

3.7

3.9

Flexural Strength

MPa

313

340

Compressive Strength

MPa

3400

3600

Modulus of Elasticity

GPa

350

380

Impact Resistance

MPa·m1/2

4

5.1

Weibull Modulus

m

10

10

Vickers Hardness

HV0.5

1800

1900

Thermal Conductivity

W/mk

24

27

Highest Application Temperature

°C

1600

1750

Volume Resistivity at 20°C

Ω.cm20

>1014

>1014

Dielertric strength

KV/mm

20

25

Thermal expansion

X10-6/K

5.0-8.3

5.4-8.3









































2.  Material



Alumina and zirconium ceramic



1) A variety of specifications available.

2) Meet various technical request

3) Lower medium spoilage

4) Good insulation performance and high temperature resistance

5) Solid texture

6) Used in all electric products, electric heating products and wear resistant machinery parts.

7) OEM, ODM and OBM are welcomed



3.Application

1) Domestic pumps:

Domestic pumps are primarily hot water circulators (central heating pumps) used in residential and office buildings pumping hot water from a central boiler system to radiators. The pump designs usually incorporate an alumina bearing with a carbon thrust bearing. Domestic appliances such as dishwashers and washing machines often incorporate pump designs using alumina/carbon based seals



2) Industrial pumps:
Industrial pumps are used in pumping water from deep wells. These pumps often use alumina thrust bearings with a lapped or polished working face, which are ideal for this application as they mate with the carbon thrust pad


3) Submersible pond pumps for garden water features and aquariums:
These typically use two alumina bearings housed in the impellor and magnetic rotor assembly, running on a stationary Alumina shaft. The bearings are usually of wider tolerances than for circulating pumps as the load and noise requirements are less demanding


4) Automotive water pumps:
Automotive water pumps often use an Alumina ceramic/carbon seal assembly because of the Alumina's high wear and corrosion resistance to anti-freeze solution


5) Vertical pumps:
Vertical pumps such as those used for pumping water above ground into high-rise residential or commercial buildings often are designed with precision-machined alumina bearings





Our production process ranges from powder molding, through working the green parts to grinding and polishing of the sintered components.



Our Ceramic Shaft & Ceramic Rods has excellent surface finish characteristics along with superior corrosion and abrasion resistance make ceramic materials the first choice for plunger pumps, high pressure cleaner and high speed rotation machinery applications. It provides 5~10 times life service higher than metal ones.

high wear resisitance Alumina/zirconia/silicon machinable ceramic rod
