pump application 99%Alumina ceramic plunger piston/sleeve
Negotiable
/ Piece
80 Pieces(Min.Order)
- 30000 Piece / Pieces per Month
- SHANGHAI
- Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Type | Ceramic Rollers | |
| Application | Industrial Ceramic | |||
| Brand Name | EB |
Product Description
Specifications
1.Precision dimension2.Wear resistance
3.Anti-corrosion
4,Shaped as your designing and requirement
95%--99% AL2O3 ceramic bushing, ceramic plunger
Material: Alumina 95% -99.5%
Customized production is aviable, for more information, please do not hesitate to tell me.Dimension, Tolerance, Surface Roughness, Concentricity, Perpendicularity and other.
Property
Items | Unit | 95%Al2O3 | 99.5%Al2O3 |
Density | g/cm3 | 3.7 | 3.9 |
Flexural Strength | MPa | 313 | 340 |
Compressive Strength | MPa | 3400 | 3600 |
Modulus of Elasticity | GPa | 350 | 380 |
Impact Resistance | MPa·m1/2 | 4 | 5.1 |
Weibull Modulus | m | 10 | 10 |
Vickers Hardness | HV0.5 | 1800 | 1900 |
Thermal Conductivity | W/mk | 24 | 27 |
Highest Application Temperature | °C | 1600 | 1750 |
Volume Resistivity at 20°C | Ω.cm20 | >1014 | >1014 |
Dielertric strength | KV/mm | 20 | 25 |
Thermal expansion | X10-6/K | 5.0-8.3 | 5.4-8.3 |
Shaped as customer requirement and drawing
