rubber belt / classical v belt

Specifications

rubber belt / classical v belt: excellent quality and most sizes.

rubber belt / classical v belt:
1 We can custom-produce according to the demands or the given sample.

2 Integrating research and manufacture together

3 We've been in rubber belt industry for more than 25 years

4 We established R&D center , Hi-tech  center, high temperature resistant rubber belt research center.

Classical v belt
Common v belt that the different types of inches length that we can manufacture:

Model	inches length	Top width(mm)	Thickness(mm)
Z	15-100	9.5	5.5
A	14-236	13	8
B	16-551	17	11
C	30-590	22	14
D	71-590	32	19
E	110-590	38	23

Ribbed belt
1 Types of PH,PJ,PK,PL,PM all can be supplied.
2 We can custom-produce according to the requirements or samples.


Banded belt
1 types of AJ BJ CJ DJ 3V 5V 8V are available.
2 Our company participated in formulating the China Chemical Industry 'Joined classical v-belts' standard.  Standard NO. HG/T 3745-2004
Joined classical v-belts,namely, banded belt

Automotive v belt:
1 Main Types of AV9.5/10,AV13/12.5,AV17/15,AV22,AV38 are available.

2 Annual output: 5,000,000 pieces

Narrow v belt:
1 Both wrapped and raw edge narrow v belt are available

2 Main Types:SPA SPB SPA SPC SPZ 3VX 5VX 8VX 3V 5V 8V

Timing belt:
1 Automotive timing belt, T type belt, arc tooth belt, double sides belt are supplied.

2 The following types are available.

The details of sizes and types

T type

Type	Pitch Pb(mm)	Tooth height ht(mm)	Belt thickness hs(mm)	Angle β°
MXL	2.032	0.51	1.14	40
XL	5.080	1.27	2.30	50
L	9.525	1.91	3.60	40
H	12.70	2.29	4.30	40
XH	22.225	6.35	11.20	40
T2.5	2.5	0.7	1.30	40
T5	5	1.20	2.20	40
T10	10	2.50	4.50	40
T20	20	5.00	8.00	40



























arc tooth belt

Gear code	Type	Pitch Pb(mm)	Tooth height Ht(mm)	Belt thickness hs(mm)
HTD	3M	3	1.17	2.4
	5M	5	2.06	3.8
	8M	8	3.36	6.00
STPD/STS	S5M	5	1.91	3.4
	S8M	8	3.05	5.3
RRP	8M	8	3.2	5.5

Southeast company manufactures rubber transmission  belts and conveyor belts.



Transmission belts includeclassical v belt, Raw-edged V belt, Ribbed V belt, Timing belt forautomobile and industry, Wrapped V belt, Narrow V belt,fanbelt,Variable speed belt, agricultural machinery, CVT belts, six-sided belt.



Conveyor belts includeEP/NN/COTTON conveyor belt, Endless conveyor  belt, High temperatureresistant conveyor belt, Heat resistant conveyor belt,Patternedconveyor belt, Oil resistant conveyor belt, Chemical resistantconveyorbelt, Food conveyor belt.



Our brands SOUTHEAST and GEMINIROPE are welcomed both in home and abroad.

Ourproducts are used to form complete set for the products of manyenterprises. And they are also exported to some countries and regionsinEurope. America, Middle East and Southeast Asia.

Our company has founded the high-tech research and development center that is cooperate with University. Therefore,we can design the produces according to client's requirements.
We also manufacture special belt when the sample was given.

Southeast Rubber Belt Co.,Ltd. wish you health and prosperity.
