Charging Station Power Supply Module

Name: Charging Station Power Supply Module
Brand: Tonhe
SKU: 104736445
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

Tonhe

Model Number:

TH400Q25NZ

Shijiazhuang Tonhe Electronics Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name Tonhe

Model Number TH400Q25NZ

Output Power Other, 10KW

Output Type Other, DC

Input Voltage 380V

Output Voltage 280-400

Output Frequency 45-65

Output Current 0-25A

Specifications

1.Soft switch in all progress
2.High efficiency, high quality, low power consumption
3.multiple protection

Model Item			TH400Q25NZ
Weight (KG)			46
Output voltage range (VDC)			280-400
Max output current(A)			0-25
Rated power(KW)			10
Input voltage(VAC)		323	323
		380	380
		437	437
Output voltage(VDC)		280	280
		340	340
		400	400
Stability precision of voltage			≤±0.5%
Stability precision of current			≤±1%
Power factor under full load			≥0.99
Total harmonic current			≤5%
Efficiency			≥91%
Storage temperature (°C)	Min		-40
	Typical		25
	Max		60
Working temperature (°C)	Min		-20
	Typical		25
	Max		50
Parallel instability			±5%
Start up time(s)			3S-8S
Load grade			Continuously operate under Grade I (100%) rated output current
Over current protection			When output current excees limit value, it comes to stable output. The output current will not increase.
Output over-voltage protection			When the output voltage exceed 420±5VDC it will automatically stop , in case of damaging the equipment
Output short circuit protection			Output voltage 0V if output short circuit, and return to normal output after removing the short circuit
