Specifications
Interactive Kiosk Touch Screen1.Full tested before shipping
2.Warranty:1 free years
3.Agency Approvals:Ce Rohs
Speicification:
Interactive Kiosk Touch Screen
1.Full tested before shipping
2.Warranty:1 free years
3.Agency Approvals:Ce Rohs
Main product:
Packing picture:
Technical Specifications
Self-Service Kiosk Terminal | |||
Model No |
WVT-AK-009CUSTOMIZED |
||
LCD Display |
TFT LCD42' |
||
Resolution |
1280 x 1024 |
||
Contrast Ratio |
500:1 |
||
Color Resolution |
16.2M |
||
Brightness |
300CD/m2 |
||
DC Adapter |
DC12V 5A |
||
Touch Technology |
Projected Capacitive Touch Screen |
||
Resolution |
4096 x 4096 |
||
Glass thickness |
3mm |
||
Deviation of Error |
2mm |
||
Light Transmission |
90%~92% |
||
Response Time |
Less than 16ms |
||
Touch Activation Force |
Less than 100g(adjust allowed) |
||
Durability |
Scratch-free; More than 50,000,000 touches in one location without failure. |
||
Surface Hardness |
Mohs’ hardness rating of 7 |
||
Controller Interface |
USB and RS232 |
||
PC Specification |
Mini PC |
||
CPU |
INTEL I3 |
||
RAM |
2 GB DDR3 |
||
HDD |
320 GB 2.5” HDD |
||
Graphics |
Inter NM10Express |
||
Chipset |
INTEL 3150 |
||
Ports |
5 x USB, 1 x VGA, 1 x LAN, 1 x AUDIO-OUT , 1 x MIC-IN |
||
Power Consumption |
30 W |
||
Operating System |
Windows 7 /Windows8 |
||
Standard Components |
|
||
Wireless |
802.11 b/g/n Wi-Fi and antenna |
||
Camera |
Mini camera |
||
Protector |
Power surge protector & breaker switch |
||
Card Device |
Pin pad and card reader |
||
Printer |
A4 brother thermal printer |
||
|
|||
|
|||
Physical Specification |
|
||
Kiosk shell material |
1.5mm cold rolled steel |
||
Color |
Silver & Blue |
||
Feet |
4 x adjustable rubber feet |
||
Fan |
2 x 12V fans |
||
Audio | Speakers |
2 x 15W Speakers, 1 x 30W Amplifier |
||
Ports | Slots |
Power input | Power switch | PC switch | USB | LAN | Volume control |
||
Cables |
Standard power cable |
||
Power Supply |
International 110–240 AC power |
||
Operating Temp | Humidity |
Temperature:+5°C ~ +50°C | Humidity:0% ~ 80% |
||
Weight & Dimension |
85, 600x500x1680mm(WxDxH) |
||
Packing Method |
Wooden crate |
||
Packing Weight & Dimension |
125kg, 650 x 550 x 1730mm(WxDxH) |
||
Customize Options |
|
||
Multi-options |
Shell design |
Operating system |
Personalized colors, finish, branding & advertising |
Screen size |
Integrated components |
Professional re-usable flight case |
|
PC upgrade |
Lockable computer & monitor & compartments |
|
|
Other Kiosk Components |
*Refer to for more details on all WiViTouch certified & accredited components |
||
Wireless Network |
3G/GPRS modem, Bluetooth, GPS receiver |
||
Printers |
60mm, 80mm, A4, ticket printers |
||
Input |
Keyboards, Touch pads, Trackballs |
||
Card Devices |
Magnetic / IC / RFID devices, Multi-card reader |
||
Payment Devices |
Debit / Credit Card Payment devices, Bill & Coin devices |
||
Scanners |
Barcode & document scanners |
||
Authentication |
Biometric devices & signature pads |
||
Power |
UPS |
||
Other |
DVD RW, Intrusion Alarm, Proximity Sensor |
||
Attention Points |
|
||
Comments |
Specifications are subject to change |
||
Please contact a WiViTouch Consultant for further information | |||
