Packaging & Delivery
Packaging Details: sodium bentonite geosynthetic clay liner
normal packing: with5.8m x length35m per roll
width and length all can be made by customrized
Delivery Detail: 10 days
sodium bentonite Geosynthetic Clay Liner (3600g/m2-7200g/m2)
other name: pond liner, clay liner, clay pond liner, large pond liners, dam liners
lake liner, landfill liner, bentonite clay liner, bentonite waterproofing
Description of geosynthetic clay liner :
EltGCL are high performance needle punched environmental reinforced composites which combine two durable geotextile outer layers with a uniform core of natural sodium bentonite clay to form a hydraulic barrier.
Fibers from the nonwoven geotextile are needle punched through the layer of bentonite and incorporated into the other geotextile (either a woven or non-woven). when hydrated under a confining load, the bentonite swells to form a low permeability clay layer with the equivalent hydraulic protection of several feet of compacted clay.
Typical physical properties of geosynthetic clay liner :
1. Improved leakage performance
2. Permanent waterproof performance
3. Simple construction and short time limit for a project.
4. Not influenced by air temperature.
5. A kind of green material and good to environmental protection.
6. More versatile than compacted clay
7. Increased airspace and liner efficiency
Potential Applications of geosynthetic clay liner :
It is used to prevent water leakages in areas of artificial lakes, waste disposal fields, underground garage, top building gardens, reservoirs, oil warehouses, and chemicals accumulating fields.
Note:
1, The EltGCL Weight can do from 4000g/m2 to 7200g/m2.
2, The EltGCL is a reinforced GCL consisting of a layer of sodium Bentonite between a woven and non-woven geotextile, which are needle punched together.
3, we also have Needle punched and coated process GCL and Viscose pmcess GCL.
