Specifications
1.Cleanroom Polyester Wiper2.100% synthetic polyester
3.Classification:Class100-1000
4.Size: 4*4" 6*6" 9*9"
5.durable
Cleanroom Polyester Wiper
Features 100% synthetic polyester (continuous-filament, double-knit polyester); Laser sealed border; Thermal method and Ultrasonic method are also available; Class10 cleanroom laundered and vacuumized, both folder and in bulk packaging options;Stable quality control, etc.
Benefits Prevents cleanroom contamination with ultraslow levels of particles and extractables; High absorbency, wettable with isopropyl alcohol; Soft, non-scratching design, etc
Applications Superior for spill control and general wiping in Class10~10,000 environments; Cleaning and polishing the floor and the products of IC, Photo-electricity and other critical industries request; Contamination control such as GMP workshop and medical region; Cleaning and polishing sensitive disk surfaces.
Test Method & Standard
Characteristics |
Test Method and Standard |
Contamination |
ASTM E 2090-00 |
Nonvolatile residue |
IES-RP-CC004.2 section 6.1.1 |
Na+, K+, Ca+, Cl-, No2- |
IES-RP-CC004.2 section 6.2 |
Products
P.N. |
Classification |
Material |
Descriptions |
Size |
GCPW01 GCPW02 GCPW03 |
Class100-10000 |
Polyester |
Laser Cut; Cleanroom Laundered and Packaged |
4”x4” 6”x6” 9”x9” |
Various products dimensions as clients specific request; Sealed methods among Laser Cut, Ultrasonic Cut, Heat Cut and Thermal Cut, etc. | ||||
Physical Characteristics
P.N. |
Performance |
Contamination |
|||
Basis Weight |
Sorptive Capacity |
Sorptive Rate |
Particle(count/m2) |
Fibers(fibers/m2) |
|
GCPW01 |
145 g/m2 |
360 mL/m2 |
0.5 sec |
1.38E+07(>0.5 um) |
5120(>10.0 um) |
GCPW02 |
115 g/m2 |
358 mL/m2 |
0.5 sec |
20 x 106(0.5-5.0 um) |
5210(>10.0 um) |
GCPW03 |
100 g/m2 |
340 mL/m2 |
0.5 sec |
24.0E+06(>0.5 um) |
4220(>10.0 um) |
Nonvolatile residue & Ions
P.N. |
Nonvolatile residue |
Ions(ug/cm2) |
||||
IPA |
Na+ |
K+ |
Ca+ |
Cl- |
No2- |
|
GCPW01 |
0.651 ug/cm2 |
ND |
ND |
ND |
ND |
ND |
GCPW02 |
0.44 ug/cm2 |
0.002 |
0.002 |
0.003 |
0.002 |
ND |
GCPW03 |
1.22 ug/cm2 |
0.008 |
0.001ug/cm2 |
0.033 |
0.005 |
ND |
Package
600 sheets/bag for 4”x4”, 150 sheets/bag for 6”x6”and 9”x9”, 10 bags/case
Remark
The data in these tables represent typical analyses of these wipers at the time of publication, is not to serve as test results. We continually refines both our products; ASTM E 2090 provides a more sensitive test and a more complete measurement of particles and fibers than other standard test methods; The test for ion content follows IES-RP-CC004.2 Document
