PCB Cleaning SMT Machine

Name: PCB Cleaning SMT Machine
Brand: Gosmt
SKU: 104688917
Availability: InStock

US$ 3,000 - 20,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Gosmt

Model Number:

GP02

Shenzhen Gosmt Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen / Hongkong

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Gosmt

Model Number GP02

Feature Critical Cleaning / Residue Free

Fuel Electric

Certification CE

Use Other, for PCB surface cleaning

Cleaning Process Other, dust particles cleaning

Cleaning Type Other, cleaning roller with esd brush

Industry Used Electronic Industry

Material Other, bare PCB board

Specifications

1.Double ESD brush clean
2.PCB size 50x50 to 460x510mm
3.Interface Molex 4-pin connectro
4.transportation height
900 to 20m

Feature

1. Fast , efficient double ESD Brush cleaning system with deionize zone

2. Desing to remove dust from bare board in the front of the production line.

3. Maintenance free

4. ESD Brush life span 5-6 month

Advantage of Brush cleaning type

Specification

Part Name	PCB Cleaning Machine
Cleaning Specification	PCB top surface cleaning with 2XESD brush
Outer Dimensions	1110(L)x600(W)x1165(H)mm(conveyor length 600mm)
Weight	Approx. 100kg
Transportation Height	900 – 20mm
Mounting Part Height	No part on top surface of PCB, maximum 25 mm from bottom surface
Power Supply	AC 100V – AC 200V 50Hz / 60Hz
Capacitance	200VA
Painted Color	White-based cream
Flow Direction	Right to Left / Left to Right
Reference	Front reference / back reference
PCB Size	L size (50 x 50 to 460 x510mm)
Interface	Molex 4-pin connector (1490R/P1)
ESD Brush Height Adjustment	Manual vertical adjustment type
Operation Panel	Push Button Buzzer Emergency stop
Breaker	Built-in
