Casing Head Assembly for Wellhead Assembly
About Company
Our company,as national high-tech enterprises,is CNPC First-Class material suppliers with many leading products-wellhead assembly,X-mas tree,choke and kill manifold etc.Our company, Passing API Q1,ISO 9001,is authorized the right to use the monogram of API 6A,API 16C,and also has the National Special Equipment A-class Manufacturing License(TS).
Company currently occupies 76000 square metres with 220 staff including 38 high and mid-level technical staff.There are about 178 sets of various processing equipment and 500 sets of testing equipment and tools.
Company will constantly invest more on scientific research,strengthen the cooperation with school-enterprise,pay attention to personnel training,and develop well-liked new products to be an excellent supplier of oilfield production,and make company go to a higher level!
Old Factory
New Factory
About Product
1.The seat bore of casing hanger for casing head and casing spool is straight structure, and the cone of hanging shoulder is 45°with fine loading ability.
2.If required, it can be designed to be integral or split structure.
3.The connection type of casing head and surface casing is weld, thread and slip.
4.The structural type of matched casing hanger: slip, thread (mandrel)
5.The connection type of side outlet includes thread, bolted flange and flange.
6.The bottom of casing head and casing spool are equipped with casing secondary seal mechanism and sealing test port.
|
Casing program |
20”—13 3/8”—9 5/8”—7” ,5 1/2” |
|
(3000Psi) Side outlet connection |
2 1/16”-3 1/8” |
|
Load Bearing |
≤5000KN |
|
Hanger type |
4” , 5” , 4 1/2” ,5 1/2” , 7”, 9 5/8”, 10 3/4” , 13 3/8” |
|
Working pressure |
14MPa(2000Psi)~140MPa(20000Psi) |
About Packing
About Machinery
Certification:(API16C,API6A,APIQ1)
Certification:(ISO9001,OHSAS18001:2007,and other cetifications)
