3304 Piston Ring, 2W1709, 3304PC, 3304DI Ring Set

3304 Piston Ring, 2W1709, 3304PC, 3304DI Ring Set thumbnail-1
3304 Piston Ring, 2W1709, 3304PC, 3304DI Ring Set photo-1
US$ 31.6 - 35.5 MOQ: 100 Sets
Key Specifications
Get Latest Price
Type:
Piston Ring
Size:
120.65
Car Make:
E330
Contact Supplier Request Quote Chat Now
Guangzhou TPK Diesel Parts Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Piston Ring
Size 120.65
Car Make E330
OE NO. 2W1709
Place of Origin Hunan, China
Brand Name TPK
Model Number 3208
Warranty 12 Months

Product Description



1: Specification For TPK Piston Ring



Item:      3304 piston ring, 2W1709, 3304PC, 3304DI ring set
Engine:     3304,3304PC,3304DI
Oem No:     2W1709
Material:    DCI/ACI
Dia(mm):  120.65
Ring Size(mm): 3.0+3.0+3.17
Moq: 10 Sets For Ex-stocks, 150 Sets for Production
Delivery: 1-3 Days for Ex-stocks,45 days for production
Packing: TPK or according to your requirements
Other Parts: Piston Ring, Piston Ring Set,Ring Piston
  Cylinder Liner, Cylinder Sleeve
  Overhaul Gasket set,Complete Gasket kit, Full Gasket Set
  Cyliner Head Gasket






Guangzhou TPK Diesel Parts Co.,Ltd

Our company's main engine parts for Ex-stocks as followings:

1: Cylinder block, cylinder head, crankshaft, camshaft, connecting rod.
2: Liner Kits. Piston kits, piston ring set, cylinder liner (sleeve), Pin bush.
3: Full gasket kit, head gasket,Oil Seal.
4: Engine bearing, Main bearing, con rod bearing,Camshaft Bearing,thrust washer
5: Engine valve, valve seat, valve guide.
6: Oil Pump, water pump,
7: Starter, alternator
8: Turbocharger





3024,3044,3046,3054,3056, 3064, 3066, 3176, 3114, 3116, 3204, 3208, 3126,
3304,3304PC,3304DI, 3306,3306PC,3306DI, 3406, 3408, 3412, 3508, 3512, 3516,
C2.2, C4.2,C4.4 C6.4 C6.6, C7, C9, C10, C12, C15, C18,
D315,D318,D330,D333,D343,D346,D348,D349,D353,D9H,D8,D8H,D8K,G3300,G3406,G3412,G353







FOR    6 Top 120.65 2.38 4.8 HB
3306 2nd 2.38 4.8 CR   211-4321
  O 4.76 5.4 CR
FOR    4~6 Top 120.65 3.175 4.6
3304 2nd 2.38 4.6     9S3068
3306 O 5.56 3.4
FOR    4~6 Top 120.65 3 4.6
3304 2nd 3 4.6     2W1709
3306 O 3.17 3.4
FOR    4~6 Top 120.65 3.17 4.6
3304 2nd 2.38 4.6     2W6091
3306 O 3.17 3.4





Other Piston ring for





3406, 3408,
3412		 1W8922 2W1521
2P2817
7N7078		 1723284
C15 N/A 1777496
1765749
1899771		 1807352
3412 N/A 1928807 1922208
3126 N/A 1979386
1979277
1979354		 1979340
G342 9H1226 4N3875
6B2174
3H0881		 1H3588
  3S4047 1S7082
9M4602
9M4603		 1M3257
3406, 3408,
3412		 1W8922 2W1521
2P2817
7N7078		 1W9372
D6B 3S4029 3S4027
3S4026
7M2126		 2M5558

2:PARTS SHOW



3304 piston ring, 2W1709, 3304PC, 3304DI ring set3304 piston ring, 2W1709, 3304PC, 3304DI ring set3304 piston ring, 2W1709, 3304PC, 3304DI ring set3304 piston ring, 2W1709, 3304PC, 3304DI ring set3304 piston ring, 2W1709, 3304PC, 3304DI ring set3304 piston ring, 2W1709, 3304PC, 3304DI ring set





3304 / 7.0L 4
Diesel
Cylinder
425 CID Stroke
Bore 4.750
6.000


(Continued)
4 5P8768 Cylinder liner oring kit (3) 5S6670, (1) 2W6134
12 5S6670 Cylinder liner oring Lower seal
4 2W6134 Cylinder liner oring Upper filler band
BEARINGS
5 4W5738 Bearing main pair Std, 3.5000 journal, 3.8160 housing bore, 1.130 length (replaces 8N8224)
5 8N8225 Bearing main pair .010
5 8N8226 Bearing main pair .020
5 8N8227 Bearing main pair .030
5 2531APA 40 Bearing main pair .040
5 2531APA 50 Bearing main pair .050
2 6N8940 Thrust plate .185 thick (replaces 6N4129)
2 9S3037 Thrust plate .232 thick (replaces 6N4129)
2 1003652 Thrust plate .214 thick (replaces 7N9342)
4 4W5739 Bearing rod pair Std, 3.0000 journal, 3.2500 housing bore, 1.504 length (replaces 8N8220)
4 8N8221 Bearing rod pair .010
4 8N8222 Bearing rod pair .020
4 8N8223 Bearing rod pair .030
2 7M4046 Bearing cam 1.008 OAL
1 9M5477 Bearing cam 1.135 OAL
4 8N0702 Bushing con rod 1.500 pin, 1.388 OAL, straight
4 8N1985 Bushing con rod 1.500 pin, tapered
4 8N0703 Bushing con rod 1.700 pin, 1.430 OAL, straight
4 8N1849 Bushing con rod 1.700 pin, tapered
GASKET & SEALS
CATGASKET NOTE For gasket sets: Call with Serial and Arrangement Numbers
1 9Y9895 Seal crankshaft front 2.625 shaft, 3.700 OD
1 2P3859 Sleeve crankshaft Front, 2.502 shaft, 2.627 effective shaft
1 9S3111 Seal crankshaft rear 6.328 shaft, 7.336 OD, lip type seal
1 2P3858 Sleeve crankshaft Rear, use with 9S3111 seal, 6.206 shaft, 6.328 effective shaft
1 4W0452 Seal crankshaft rear 6.198 shaft, 7.336 OD, directional type, late
1 7C4297 Seal crankshaft rear 6.202 shaft, 7.336 OD, directional type seal, late, double lip (4W0452 single lip)
1 8S1963 Gasket oil pan
CAMSHAFT
1 7C3862 Camshaft [9Y1723 cam kit]
8 7S3161 Lifter Solid type
VALVE TRAIN
CYLHEAD NOTE For complete and bare cylinder heads - Refer to Cylinder Head Catalog or Call with casting
4 1007860 Valve intake 2.020 head dia, 5.350 length, .3717 stem, 30 deg, 2G, stellite (replaces: 6N9915, 2W2620, 7N0572)
DI: Turbo & Natural
4 5S6452 Valve intake 2.020 head dia, 5.510 length, .3717 stem, 30 deg, 2G
IDI: Natural
4 2W2621 Valve intake 2.020 head dia, 5.510 length, .3717 stem, 30 deg, 2G, Stellite (replaces 4W1670, 7S8809, 9N6117)
IDI: Turbo, Spark ignited short
4 7W7490 Valve intake 2.020 head dia, 6.437 length, .3717 stem, 30 deg, 2G
Spark ignited long
4 6N9915 Valve intake 2.020 head dia, 5.369 length, .3717 stem, 30 deg, 2G (CAN USE 1007860)
DI: Natural
4 1487455 Valve exhaust 1.896 head dia, 5.285 length, .3717 stem, 30 deg, 2G, stellite (replaces 1007861, 6N9916, 7N0573)
DI: Turbo & Natural
4 5S6449 Valve exhaust 1.896 head, 5.469 length, 0.3717 stem, 30 deg, 2G [can use 8N0875]

4 2W2877 Valve exhaust 1.896 head dia, 5.469 length, .3717 stem, 30 deg, 2G
Spark ignited short
4 8N0875 Valve exhaust 1.896 head dia, 5.469 length, 0.3717 stem dia, 30 degree, 2G, stellite [repl 7S6767]
IDI: Turbo, Natural
4 7W7491 Valve exhaust 1.896 head dia, 6.396 length, .3717 stem, 30 deg, 2G
Spark ignited long
4 7N0573 Valve exhaust 1.896 head dia, 5.308 length, .3717 stem, 30 deg, 2G (CAN USE 1487455)
DI: Natural
8 1621589 Valve guide 0.3741 ID, 0.6583 OD, 2.781 length (repl: 1487425, 1487502, 1167553, 1090390, 1033298, 2P1262,
5S4598)
8 4W9176 Valve guide 0.3750 ID, 0.6580 OD, 2.775 length (replaces: 7N4310) Natural gas, short valve engine
8 7E1551 Valve guide 0.3750 ID, 0.6580 OD, 2.640 length; Natural gas, short valve engine, improved cooling
8 9Y7895 Valve guide 0.3750 ID, 0.6580 OD, 3.700 length; Natural gas, long valve engine
16 2A4429 Valve lock 0.372 stem dia, 2G, 7 degree
8 1W5300 Rotocap Includes 6N7174 shield
8 1031800 Rotator without shield [repl 8N7782, 5S5874]
8 7S7144 Valve spring 1.373 OD, .185 wire dia, 2.085 free
CRANKSHAFT
1 4N7692 Crankshaft Flange: Flat, 9 bolt hole; Snout: taperded, 1 keyway, 1 bolt hole
1 1678123 Vibration damper
CONNECTING ROD
4 0R0915 Connecting rod Reman, 1.50 pin tapered; cast# 8N1720, part# 8N1984; bushing 8N1985
4 5S6360X Connecting rod Reman, 1.50 pin straight; cast# 2P0933, 6N8068; part# 8N1984; bushing 8N0702
4 0R0914 Connecting rod Reman, 1.70 pin tapered; cast# 8N1720, part# 8N1721; bushing 8N1849
4 5S2793X Connecting rod Reman, 1.75 pin straight; cast# 2P0933, 6N8068; part# 8N1721; bushing 8N0703
8 1P9956 Bolt connecting rod
8 5S6348 Nut connecting rod





3:FACTORY WORKSHOP AND INTRODUCTION

3304 piston ring, 2W1709, 3304PC, 3304DI ring set3304 piston ring, 2W1709, 3304PC, 3304DI ring set3304 piston ring, 2W1709, 3304PC, 3304DI ring set3304 piston ring, 2W1709, 3304PC, 3304DI ring set




Packaging & Shipping



Packing:

1: TPK packing

2: acording with your requirments

Shipping



(1): By sea

(2): By air

(3): By express (DHL, FEDEX, TNT, EMS... )


Our Services

1: 24 hours Onliner service

2: repying your inquiry list in 8 hours by email


Payment



(1): TT (30 %  in Advanced, 70 % before Shipment)
(2): Western Union
(3): Cash



Related Parts



         Piston Kit, cylinder liner, gasket set, other engine parts


Company Information









Guangzhou TPK Diesel Parts Co.,Ltd, Build in 1996, is a professional  manufacturer on Diesel Piston, Piston ring, Cylinder Liner, Head Gasket & Overhaul Gasket Kit. TPK has been cooperating with OEM factory in China for several years, running business mainly in imported diesel engines . All products in TPK have passed the national quality supervision on combustion engines and obtained certificates from ISO9002.



Till now, TPK has four storehouses in Guangzhou, occupying an area of over 5,000 square meters. The number of employees in TPK reaches up to 100, among which include 20 sales personnel in China, 15 sales personnel outside China, 10 QC personnel. TPK products command a ready market in Europe, Middle East, South America, North America, and Southeast Asia and are well received.



With the principles of international brand, good quality, shared resources, and serving the world, TPK endeavors to provide perfect accessories replacement solutions for customers. TPK is ready to cooperte with you to reach a win-win future.
