Industrial PVC High Speed Shutter Doors/Fast Rolling Door
High speed door to bring fast, safty and efficient new experience. We have a perfect quick product line to make your plant more efficient and energy. Adapted to the conditions of pressure or negative pressure<35 kg/m2 interior openings inatallation.
Description of Industrial PVC High Speed Door | |
Motor Brand: |
SNMA, SEW, BS |
Input Voltage: |
220V 50HZ / 380V 50HZ |
Motor Power: |
750W - 2200W |
Running Speed: |
0.7 - 1.2 M/S (Depends) |
PLC Control Panel: |
MITSUBISH, IDEC, KEWEI(China) |
Inverter / AC Driver: |
SHIHLIN |
Revolving encoder: |
TOFI |
Curtain Material: |
SIOEN high-strength polyster textile fiber, with bothside polyvinyl chloride coating |
Curtain Thickness: |
0.8mm, 1.0mm |
Curtain Color: |
Yellow, Red, White, Blue |
|
Wind Resistance Pressure: |
180 N/M2 |
Tolerancde Frequency: |
10 times/min, Inverter opening 800-1000 times/day |
Steel Construction: |
Made of 2.0mm cold-roll steel plate from BAO Steel, with painted treatment |
Safety Performance: |
Infrared beam protection system |
Standard Control mode: |
Touching type wall switch |
Emergency operation: |
Available |
Optional Control Mode: |
Geomagnetic right, Radar, Stretcing wire switch, Linkage interlock, Pull rope, etc |
Features
1. High intensity fire insulation, sound insulation, spray the surface corrosion.
2. Install tamper device, effectively protect your property.
3. Bearing pulleys easy adjustment to ensure smooth lifting process without noise
4. Double security guards, fall protection + anti-fracture "
5. Using frequency: 2000 times a day
6. Convenient to operate
7. Visible window available
Overview
1. φ140 Transmission shaft
2. motor housing and transmission system
3. door curtain
4. aluminum alloy reinforce rib
5. PVC transparent door curtain
6. infrared photoelectric switch
7. track cover
8. safety air bag
9. 220V/380V power
10. drive system
11. control power line
12. control box
13. shaft case
14. aluminum alloy reinforce rib
15. PVC transparent door curtain
16. PVC fabric curtain
For Motor
1. Low MOQ: One set is available for checking our quality first conveniently.
2. Good Quality: Your client satisfied on our quality. You can get good reputation from your market
and obtain more orders.
3. Good Service: Our professional service before and after sale.
4. The reasonable price
5. Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).
6. OEM is welcome
