Home > Electrical & Electronics > Connector & Terminals > Wire to Wire Connector > High Frequency Cable Assembly, RF Coaxial Cable Connector With Male SMA to Female UHF Connector
High Frequency Cable Assembly, RF Coaxial Cable Connector With Male SMA to Female UHF Connector
US$ 4.8 - 10.4
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SH-Link
Model Number:
SMA-UHF
Payment & Shipping
Payment Methods:
Port of Shipment:
HK port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cable Assembly, Female FAKRA to BNC Connector With Cable RG 316 for High Frequency CommunicationUS$ 1.2 - 1.56MOQ: 100 Pieces -
RF Connector, BNC Cable Assembly for High Frequency CommunicationUS$ 1.2 - 1.56MOQ: 100 Pieces
-
Cable Assembly for FAKRA Connector With Cable RG 174 for CommunicationUS$ 1.2 - 1.56MOQ: 100 Pieces
-
Cable Assembly, High Frequency Test Cable for Cable Semi-flex 141with SMA/N ConnectorUS$ 1.38 - 1.56MOQ: 100 Pieces
-
Cable Assembly, One Connector to One Connector for Cables RG 174/178/316 RF Coaxial ConnectorUS$ 4.8 - 200MOQ: 100 Pieces
Place of Origin
Guangdong, China
Brand Name
SH-Link
Model Number
SMA-UHF
Type
Other, cable assembly
Application
RF
Gender
Other, male/female
Product Description
| Temperature range | -55—+155℃(PE Cable -40—+85℃) | |||
| Vibration | 100m/S²(10-500Hz)10g | |||
| Impedance | 50Ω | |||
| Frequency range | DC-18GHz | |||
| Working voltage | 500V r.m.s at sea level | |||
| Withstanding voltage | 2500V r.m.s at sea level | |||
| Contact resistance | ||||
| Center contact | ≤1 mΩ | |||
| Outer contact | ≤1 mΩ | |||
| Insulation resistance | ≥5000MΩ | |||
| Center conductor retention force | ≥0.56N | |||
| Insertion loss | ≤0.24dB(6GHz) | |||
| Voltage Standing Wave Ratio | ||||
| Straight | ≤1.15/6GHz | |||
| Right angle | ≤1.25/6GHz | |||
| Coupling nut retention force | 450N | |||
| Durability(mating) | ≥500(Cycles) | |||
Our service advantage
1) factory sell directly & a good service
2) long-term, strong and steady supplying ability
3) delivery time: 5-7 working days
4) ex-factory price and competitive price
5) do as your requirements on package, brand or other designs
