Help CenterFAKRA Z Female to FAKRA Z Female Cable Assemblies With LMR100, rf Coaxial Cable
Related Products
-
RF Pigtail Cable, N Male to N Male Connector, With Rated Voltage of 60V ACUS$ 0.3 - 1MOQ: 1000 Pieces -
Female Fakra With the Coaxial Cable,Cable AssemblyUS$ 0.2 - 2MOQ: 1000 Pieces
-
n Male to Sma Types of Cable Joints, Pigtail Catheter Cable AssemblyUS$ 0.2 - 2MOQ: 1000 Pieces
-
[UL Listed]SMA,SMB,N,TNC,SMP,MMCX,MCX Waterproof Coaxial Connector Cable AssemblyUS$ 0.1 - 3MOQ: 500 Pieces
-
MMCX Connector rf Cable AssemblyUS$ 0.15 - 1MOQ: 1000 Pieces
Electrical specifications:
Frequency range: DC to 6GHz
Connector: blue female to blue female
Application GPS: telematics or navigation
Cable type: RF1.13/RG178/RG316/RG174
Cable length: 100mm (according to customer requirement)
Impedance: 50 Ohms
Temperature range: -40 to +85℃
Rated voltage: 60V AC
Contact resistance: 20m Ohms (maximum), signal and ground
Withstand voltage: 200V AC
Insulation resistance: 500m Ohms (minimum)/100V DCVSWR: <1.5:1
| Connector on first | ... connector | Depends on your needs |
| Connector on second | ...connector | |
| Cable type | ... | |
| Cable length | .. cm | |
| Packing | Neutral packing or customized |
Temperature Range |
-55~+155°C (PE Cable -40~+85°C) |
|
Impedance |
50Ω |
|
Vibration |
98m/S2 (10~2000Hz), 10g |
|
Frequency Range |
DC-12.4GHz(semi-rigid cable DC-18 GHz) |
|
Insertion Loss |
≤ 0.15dB/6GHz |
|
Withstanding Voltage |
1000V r.m.s at sea level |
|
Working Voltage |
335Vr.m.s at sea level |
|
Insulation Resistance |
≥ 5000 MΩ |
|
Durability |
≥ 500(cycles) |
|
Contact resistance: |
CenterContact ≤ 3mΩ |
|
|
Outer Contact ≤ 2.5mΩ |
|
Voltage Standing Wave Ratio: |
Straight |
flex cable ≤ 1.10+0.02f |
|
|
Semi-rigid cable ≤ 1.07+0.018f |
|
Right angle |
flex cable ≤ 1.20+0.03f |
|
|
Semi-rigid cable ≤ 1.17+0.02f |
Shipping :
1.The parts from us are sure to have quality warranty,and they are double tested before shipping.
2. The items can be sent within 7-10 working days after the payment reaches us,except for mass process, we will confirm the delivery in advance.
3. We can send your order by UPS/DHL/TNT/ FedEx. Pls contact us directly and we will use your preferred ways
Why choose us ?
1.OEM & ODM are warmly welcome
2.Good service and delivery on time
3. high gain with luxury design
4. several years manufacturing experience
5.Customized packing and customer's logo are accepted.
6.Sample order is welcome and it can be free if you are real customer.
7.Accept various transportation ways.like by express, by sea, by air and also specified freight company.
8.Strong production ablility:Monthly output is over 50000pcs.
9.Professional factory directly sale all over the wrold.
This product is a universal product, we can customize your
products according to your demand.
