Help Centerrf Coaxial SMC Connector for Flexible Cable
Related Products
-
Google N to UHF Displayport Female to Hdmi Male Adapter Plants ManufacturingUS$ 0.1 - 2MOQ: 100 Pieces -
Free Samples N Male to UHF Male Universal Travel Adapter Connectors.US$ 0.2 - 0.8MOQ: 100 Pieces
-
rf Coaxial SMA to RPSMA Male and Female Electrical ConnectorUS$ 0.1 - 1MOQ: 100 Pieces
-
Female to Female Sma Chint Connector Buy Wholesale Direct From ChinaUS$ 0.3 - 1.3MOQ: 100 Pieces
-
SMA Right Angle Male and Female Electrical Brass ConnectorUS$ 0.1 - 1MOQ: 1000 Pieces
Type SMC is one kind of miniature RF coaxial connectors which adds the thread connection form on the basis of SMB. Characteristic impedance is 50Ω.The Characteristic of connectors is in small volume,light weight,reliable connection,great ibration performance.They are used in connecting RF coaxial cable in radio equipments and instuments.
Our company was certified to ISO9001 and TS 16949. We are professioinal manufactur of RF coaxial connector designed and all kinds of adaptor,inpedance converter,fixed attenuator,termination loading and arrester etc.
The products produced according to the international standard of Farka series,SMA,SMB,SMC,BNC,TNC,N,MMCX,MCX,SSMA,SSMB ,F, etc.
In our trade merchants of various countuies,we always adhere to the principle of mutual benefit.
| MAJOR TECHNICAL CHARACTERISTICS | ||
| Temperature range | -55—+155℃(PE Cable -40—+85℃) | |
| Impedance | 50Ω | |
| Frequency range | DC-6GHz | |
| Working voltage | 335V r.m.s at sea level | |
| Withstanding voltage | 1000V r.m.s at sea level | |
| Contact resistance | ||
| Center contact | ≤6mΩ | |
| Outer contact | ≤2.5mΩ | |
| Insulation resistance | ≥5000MΩ | |
| Center conductor retention force | ≥0.28N | |
| Insertion loss | ≤0.24dB/6GHz | |
| Voltage Standing Wave Ratio | ||
| Straight | ≤1.30/3GHz | |
| Right angle | ≤1.45/3GHz | |
| Durability(mating) | ≥500(Cycles) | |
| Material & Plating | ||
| body | brass | nickel plated |
| pin contact | brass | gold plated |
| socket contact | beryllium-copper | gold plated |
| resilient contact | beryllium-copper | gold plated |
| insulator | PTFE | |
| crimp ferrule | copper alloy | nickel or gold plated |
| O-ring sealing | 6146 silicone rubber | |
| Applicable standard | ||
| MIL-C-39012 | ||
| CECC 22140 | ||
| IEC-60169-9 | ||
| DIN47225 |
Shipping :
1. The parts from us are sure to have quality warranty,and they are double tested before shipping.
2. The items can be sent within 7-10 working days after the payment reaches us,except for mass process, we will confirm the delivery in advance.
3. We can send your order by UPS/DHL/TNT/ FedEx. Pls contact us directly and we will use your preferred ways.
1.Faster delivery:Fast delivery 3 days for sample order,15 days for formal order.
2.High warranty,strictly test by QC before shipping.
3.Customized packing and customer's logo are accepted.
4.Sample order is welcome and it can be free if you are real customer.
5.Accept various transportation ways.like by express, by sea, by air and also specified freight company.
6.Excellent service-Nearly no MOQ,Reply,answer,resolve anytime.
7.Strong production ablility:Monthly output is over 50000pcs.
8.Professional factory directly sale all over the wrold.
This product is a universal product, we can customize your
products according to your demand.
