Help CenterManufacturer China SMA t Shape 3 Pin Connector
Related Products
-
Right Angle Clamp N Connector,zebra Elastomeric ConnectorsUS$ 0.30 - 0.30MOQ: 100 Pieces -
Products TNC To SMA Electrical Connector AdapterUS$ 0.5 - 2MOQ: 100 Pieces
-
Male and Male Electrical N to SMB Quick Adapter ConnectorUS$ 0.2 - 0.9MOQ: 100 Pieces
-
Hot N Male to BNC Male Connector,if AdaptorUS$ 0.2 - 1.9MOQ: 100 Pieces
-
Best Buy Male SMA to Female SMB Adapter ConnectorUS$ 0.45 - 1MOQ: 1000 Pieces
sma type,"Tee" for three female adaptor,50Ohm
rf adaptor
Adaptor is the basic product that used in the connection between the instrument cables with different interface.
there are two kinds type: within-type adaptor and inter-type adaptor.
the technical special characterestic is the same as class product.
Our company was certified to ISO9001 and TS 16949. We are professioinal manufactur of RF coaxial connector designed and all kinds of adaptor,inpedance converter,fixed attenuator,termination loading and arrester etc.
The products produced according to the international standard of Farka series,SMA,SMB,SMC,BNC,TNC,N,MMCX,MCX,SSMA,SSMB ,F, etc.
In our trade merchants of various countuies,we always adhere to the principle of mutual benefit.
| MAJOR TECHNICAL CHARACTERISTICS | |
| Temperature Range | -55~ +155°C (PE Cable -40~ +85°C) |
| Vibration | 98m/S2 (10~2000Hz) 10g |
| Impedance | 50Ω |
| Frequency range | DC~12.4GHz(Semi-Rigled Cable DC-18GHz) |
| Working Voltage | 335V r.m.s at sea level |
| Withstanding voltage | 1000V r.m.s at sea level |
| Contact resistance | Center contact<=3m Ω Coter contact<=2.5m Ω |
| Insulation resistance | >=5000MΩ |
| Center conductor retentin force | >=0.28N |
| Coupling nut retentin force | >=180N |
| Insertin loss | <=0.15 dB/6GHz |
| Voltage Standing Wave Ratio | Straight flexible cable <=1.10+0.02f semi-rigid cable <=1.07+0.018f Right Angle flexible cabl <=1.20+0.03f semi-rigid cable <=1.17+0.02f |
| Durability(mating) | >=500 times (cycles) |
| MATERIAL & PLATING | ||
| Body | brass | gold plated |
| pin contact | brass | gold plated |
| socket contact | beryllium-copper | gold plated |
| resilient contact | beryllium-copper | gold plated |
| insulator | PTFE | |
| crimp ferrule | copper alloy | nickel or gold plated |
| o-ring sealing | 6146 silicone rubber | |
MIL-C-39012;
CECC 22110;
IEC-60169-15
Shipping :
1. The parts from us are sure to have quality warranty,and they are double tested before shipping.
2. The items can be sent within 7-10 working days after the payment reaches us,except for mass process, we will confirm the delivery in advance.
3. We can send your order by UPS/DHL/TNT/ FedEx. Pls contact us directly and we will use your preferred ways.
1.Faster delivery:Fast delivery 3 days for sample order,15 days for formal order.
2.High warranty,strictly test by QC before shipping.
3.Customized packing and customer's logo are accepted.
4.Sample order is welcome and it can be free if you are real customer.
5.Accept various transportation ways.like by express, by sea, by air and also specified freight company.
6.Excellent service-Nearly no MOQ,Reply,answer,resolve anytime.
7.Strong production ablility:Monthly output is over 50000pcs.
8.Professional factory directly sale all over the wrold.
This product is a universal product, we can customize your
products according to your demand.
