Best-selling ! Underwater Monitor&pipe Inspection SystemsMCD-710

Best-selling ! Underwater Monitor&pipe Inspection SystemsMCD-710 thumbnail-1
Best-selling ! Underwater Monitor&pipe Inspection SystemsMCD-710 photo-1
US$ 650 - 650 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
MCD
Model Number:
MCD-710A/B
Contact Supplier Request Quote Chat Now
Shenzhen MCD Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shezhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name MCD
Model Number MCD-710A/B

Specifications

1.Anytime anywhere enjoy underwater
2.Small place of people could not ente

best-selling ! underwater monitor&pipe inspection systemsMCD-710best-selling ! underwater monitor&pipe inspection systemsMCD-710best-selling ! underwater monitor&pipe inspection systemsMCD-710

Specification

camera
1. camera size:23mmx120mm   front size:45mm
2.Camera case material:stainless steel house stainless steel 304
3. Camera glass material:sapphir glass
4. sensor size:1/4 inch
5.Total Pixels:PAL:720X576    NTSC: 720X480
6. view angle:120°.
7. camera light:12PCS white LEDS.
8. Special gold point touch connector
9. waterproof:IP68
10.camerawork current:100MA      camara power supply:DC 12V
11. LEDS ADJUASTABLE.
12.Work temperature:-10°C-50°C

monitor
1. monitor size:  7inch  TFT color monitor
2. monitor Total Pixels:1440X234
3. monitor power supply:DC 12V
4. osd language: english
5. up,down  left,right adjustable.
6. 16:9  4:3 model
7. sunshade includ
8. waterproof connector
9. Work temperature:-10°C-50°C

DVR
1. DVR power supply: 12V
2. DVR work current:  200MA
3. storage medium:SD card (max 32G)
4. dagital clock and dagital calendar
5. DVR Total Pixels: 720X576   (D1)
6. picture snap and movie record
7. movie format: AVI
8. audio record (yes)
9. double earphone output

Audio input unit
1. micphone
2. clip type

Cable wheel
Cable size:320MM(diameter)X110(h)
Wire material: fiberglass rod
Fiberglass length:20M( standard)
Fiberglass diameter:4.8MM
Fiberglass color:yellow

battery
Battey pype:  12V 4000MAH     rechargable li –ion battery(18650)
Tatal work time :   7  hours.

charger
input: AC90-260V        output: DC 12V    1000MA
Output cable length:1.5M
DC plug diameter :2.1MM

box
box material:fire protection
Box size:48cm x 39cm x 19.5cm

SKIDS size
1. SKIDS1: Φ40MM
2. SKIDS2: Φ80MM

Weight and cartoon size
net weight: 7.5KG
gross weight: 8.5KG





With a very flexible Stainless steel lens:



More details please contact Nicole







MONITOR

7" TFT COLOR monitor : picture resplution :320(TV Line) OSD Distply

Video output: 1Vpp 75 OHMS

Video1 video2 selector button

image up and down  left and right button

menu button (include bright conrast color language 16:9  4:3 sleep)

Sub menu down  selctor

Sub menu up selector

power on/off button

 also can  used   with remote

Power supply

charge adaptor : 110-240VAC,12.6VDC/1000mA (include)

lithium battery box (4000mAh,include)

Dimensions

case:48cm*41cm*19.5cm

camera:dimeter 23mm*120mm

cable :reel dimeter 32cm

it  is wide  used at   building operation, under water detecting  and  so on
