SHG630 PE pipe fitting welding machine
Detailed Product Description
1 Suitable for fabricating Elbow, Tee, Cross fittings of PE, PP, and PVDF in workshop
2 Pipe size: 315mm~630mm
Application and Features:
* Suitable for fabricating elbow, tee, cross and Y shape (45&60) fitting of PE, PP, PVDF in workshop. Also used to lengthen the injection moulded fitting or make the integrated fitting.
* Integrated structure. Nothing remains but to choose the different special clamps while fabricating different fittings.
* Removable PTFE coated heating plate.
* Electric planing tool with safety limit switch enable to start it only when it is locked in the operation position.
* Low starting pressure and high reliable seal structure.
* Separate two-channel timer records times in socking and cooling phases.
* Digital pressure meter enables to control pressure accurately.
* linear guide ways are equipped with heating plate and planing tool and dragging plate.
* Products comply with 98/37/EC and 73/23/EEC standards
Optional parts:
* Special clamps for welding flange stub
* Special clamps for short spigot fitting
*Special clamps for welding Y shape(45° and 60°) fittings.
Model |
SHG630 |
Pipe Sizes |
315,355,400,450,500,560,630 |
Application |
0~90°elbow, tee, cross, wyes(optional parts should be used) |
Heating Plate Max. Temp. |
270°c |
Temp. deviation in surface |
±7°c(170~250) |
Pressure |
016MPa |
Working Voltage |
380V,50Hz |
Heating Plate Power |
22 KW |
Hydraulic unit power |
2.2 KW |
Planing tool power |
4.0KW |
Total Power |
28.2 KW |
Total Weight |
Our company WUXI SHENGDA PLASTIC PIPES WELDING MACHINE CO., LTD is the leader manufacturer of buttfusion equipment in China. We occupy the 70% domestic market and export to more than 45 countries. We specialize in producing a complete range of internationl standard butt fusion equipment including field welding machine, workshop fitting machine, pipe saw, all the optional parts and tools required under the ISO9001 system and approved to CE standards by SGS
.
