Help Center6V180AH Lead Acid Battery Solar Battery
Related Products
-
6V105AH Lead Acid Battery UPS BatteryNegotiableMOQ: 1 Piece -
Shen Zhen Battery OPZV(GEL) 2V250AH Solar BatteryNegotiableMOQ: 1 Piece
-
ShenZhen Lead Acid Battery /UPS Battery/12V38AH Solar BatteryNegotiableMOQ: 1 Piece
-
ShenZhen Sealed Lead Acid Battery /6V4AHNegotiableMOQ: 1 Piece
-
ShenZhen Battery Motorcycle Battery 12N5-BS(12V5AH)NegotiableMOQ: 1 Unit
Specifications
Sealed Lead acid battery Gel battery1.Low rate of self-discharge
2.Maintenance free
3.No pollution and no harm
&Specifications
| 1)UPS battery ,Emergency battery,Solar Battery/6V180AH |
| 2) 260*180*247mm |
| 3) 5-9 years Desigh life |
| 4) 10 years manufacturer |
| 5) 1 years warranty |
Battery Construction
COMPONENT |
Positive plate |
Negative plate |
Container |
Cover |
Safety valve |
Terminal |
Separator |
Electrolyte |
RAW MATERIAL |
Lead dioxide |
Lead |
ABS |
ABS |
Rubber |
Copper |
Fiberglass |
Sulfuric acid |
Charging Methods
Application |
Charging method |
Charging Voltage at 25°C |
Temperature compensation coefficient of charging voltage |
Max.charging current
|
Charging time 25°C(h) |
Temp (°C) |
|
|
100% discharge |
50% discharge |
||||||
|
For standby power source |
Constant voltage & Constant Current Charging (with current restriction) |
6.75-6.90V |
-20 mV/°C |
54A |
24 |
20 |
0~40 (32~104°F) |
|
For cycle service |
7.30-7.50V |
-30 mV/°C |
54A |
16 |
10 |
||
*Temperature compensation of charging voltage is not needed.when using the batteries within 15°C to 35°C range.
Discharge Constant Current (Amperes at 77°F25°C)
F.V/Time |
5min |
10min |
15min |
30min |
45min |
1h |
2h |
3h |
5h |
8h |
10h |
20h |
1.60V |
631 |
504 |
360 |
207 |
148 |
117 |
63.1 |
45.5 |
31.0 |
20.3 |
17.0 |
9.12 |
1.65V |
612 |
487 |
343 |
203 |
145 |
116 |
62.5 |
45.4 |
30.7 |
20.3 |
17.0 |
9.12 |
1.70V |
576 |
451 |
324 |
199 |
144 |
115 |
62.2 |
45.1 |
30.7 |
20.2 |
16.7 |
9.04 |
1.75V |
504 |
379 |
307 |
189 |
142 |
114 |
61.2 |
44.5 |
30.7 |
19.9 |
16.7 |
9.04 |
1.80V |
451 |
324 |
288 |
163 |
140 |
112 |
59.5 |
43.2 |
30.2 |
19.9 |
16.3 |
8.88 |
& The battery can be used for
1.Emergency lighting system
2.UPS and computer standby power supply
3.Alarm system
4.Telecommunication system
5.Solar energy generating system
6.Wind energy generating system
7.Fire-fighting equipment standby power supply
& AGM 6V180Ah Lead acid battery / Emergency battery/Solar Battery /UPS Battery Characteristics
1. Excellent safety performance: No electrolyte leakage, battery swelling and cracking under normal use. |
|
2. Good discharging performance: With smooth discharging voltage and mild discharging platform.
|
|
3. Good shock-proof performance: The fully charged and completely fixed battery, with 4mm amplitude and 16.7HZ frequency do have a normal open circuit voltage without leakage, batteries swelling or cracking problem after one-hour vibration.
|
|
4. Good impact-proof performance: The fully charged battery is proved to maintian normal open circuit voltage and be without leakage or batteries swelling or cracking after droping three times from 20cm height naturally to a 1 cm-thick hardwood board.
|
5. Good resistance to overdischarge: In temperature of 25 degrees Celsius, the fully charged battery discharges with fixed resistance which is equivalent to the one required by 1 CA discharge of the battery for three weeks, and it can restore capacity over 75%. |
Your inquiry will be reply within 24 Hours ,Hope the battery is suit for your requirement.
