AGM Battery/UPS Battery/6V9AH Lead acid battery

Battery Construction

Charging Methods

*Temperature compensation of charging voltage is not needed.when using the batteries within 15°C to 35°C range.

F.V/Time

5min

10min

15min

30min

45min

1h

2h

3h

5h

8h

10h

20h

1.60V

31.5

25.2

18.0

10.4

7.38

5.85

3.15

2.28

1.55

1.02

0.85

0.46

1.65V

30.6

24.3

17.1

10.2

7.29

5.81

3.12

2.27

1.54

1.02

0.85

0.46

1.70V

28.8

22.5

16.2

9.90

7.20

5.76

3.11

2.25

1.53

1.01

0.84

0.45

1.75V

25.2

18.9

15.3

9.36

7.11

5.67

3.06

2.22

1.53

1.00

0.84

0.45

1.80V

22.5

16.2

14.4

8.10

7.02

5.58

2.97

2.16

1.51

1.00

0.82

0.44

1. Excellent safety performance: No electrolyte leakage, battery swelling and cracking under normal use.

2. Good discharging performance: With smooth discharging voltage and mild discharging platform.

3. Good shock-proof performance: The fully charged and completely fixed battery, with 4mm amplitude and 16.7HZ frequency do have a normal open circuit voltage without leakage, batteries swelling or cracking problem after one-hour vibration.

4. Good impact-proof performance: The fully charged battery is proved to maintian normal open circuit voltage and be without leakage or batteries swelling or cracking after droping three times from 20cm height naturally to a 1 cm-thick hardwood board.

5. Good resistance to overdischarge: In temperature of 25 degrees Celsius, the fully charged battery discharges with fixed resistance which is equivalent to the one required by 1 CA discharge of the battery for three weeks, and it can restore capacity over 75%.
