Home > Products > New Products > QCM200 gasoline injector testing and cleaning tester
QCM200 gasoline injector testing and cleaning tester
- 10000 Set / Sets per Month
- qingdao port
- T/T Credit Card
Product Details
Place of Origin: | China | Brand Name: | nantai | Model Number: | QCM200 |
Power: | Electronic | Usage: | Auto Testing Machine |
Product Description
QCM200 Gasoline injector tester and cleaner
This product is applicable to diagnose and clean fuel injectors of various cars manufactured worldwide, improving stability, reliability and reducing pollution. It can perform automatic detecting, analyzing and cleaning.
Main functions
It can not only diagnose and analyze the performance of the fuel injector, but also inspect dribbling, atomization, injecting angle, distributive value, uniformity coefficient, and their on off cycle, etc of single or multiple fuel injectors.
1.Can do reverse flushing, flush-back cleaning, ultrasonic flushing, and disaffiliation-free flushing to one or more fuel injectors
2. Automatically simulate the overall process under various pulse width and engine speed.
The operation status of the fuel injectors can also be observed whether at acceleration and deceleration.
3. Can manually set time, pulse width and rotation speed of the fuel injector,
and observe the performance under varied parameters. Ease and convenience of operation.
4. Can determine the shortest on-off cycle and the quality of the injector
5. Can do oil circuit testing, and disaffiliation-free flushing to the engine
Technical Parameter
l Voltage: AC220V±10% 50HZ 500W
l Operation Temperature: -10C°~40ºc
l Tank Capacity: 4L
l Test Tube Capacity: 120CC
l Ultrasonic Frequency: 40KHZ
l Rotation Speed: 0~10000r/min
l Step: 50r/min
l Time Counting Range: 0~10000 sec
l Step: 50 sec (adjustable)
l Oil Pump Pressure: 1.8kg/cm²----10kg/cm²
l Fuel Flow: 4.5 L/min
We are the leading manufacturer in Diesel Injection Pump Test Bench and Turbocharger in China, already sold more than 100 Countries, include EUI/EUP tester with Cam box, EDC VP37 tester, VP44 teser,RED4 EDC, HEUI tester, DENSO ECD-V3,V4,V5 pump tester,PT Cummins Pumps and Injectors tester, Common Rail injectors and Common Rail Pump tester( CRDI) and Turbo Charger, Spare parts(plunger, nozzle, head rotor, injector...) also different model tools for pumps and injectors repair. Hope to cooperate with you.
