BC3000 Diesel Pump Test Bench Check Bosch Denso Injection Pump

BC3000 Diesel Pump Test Bench Check Bosch Denso Injection Pump thumbnail-1
BC3000 Diesel Pump Test Bench Check Bosch Denso Injection Pump thumbnail-2
BC3000 Diesel Pump Test Bench Check Bosch Denso Injection Pump thumbnail-3
BC3000 Diesel Pump Test Bench Check Bosch Denso Injection Pump thumbnail-4
BC3000 Diesel Pump Test Bench Check Bosch Denso Injection Pump photo-1
BC3000 Diesel Pump Test Bench Check Bosch Denso Injection Pump photo-2
BC3000 Diesel Pump Test Bench Check Bosch Denso Injection Pump photo-3
BC3000 Diesel Pump Test Bench Check Bosch Denso Injection Pump photo-4
US$ 3,000 - 7,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Voltage:
220V/380V
Power:
7,5KW,11KW,15KW,18.5KW
Certification:
CE/ISO
Contact Supplier Request Quote Chat Now
Taian Nantai Experimental Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Voltage 220V/380V
Power 7,5KW,11KW,15KW,18.5KW
Certification CE/ISO
Applicable Models auto car
Place of Origin China
Brand Name nantai
Model Number BC3000
Warranty 11 Years

BC3000 diesel injection pump test bench  2014 BEST ON SALE



Introduction

BC3000 is a kind of fuel injection pump test bench adopt industrial pc with color CRT, It's the newly researched production for the direction of high power and safety to the environment.  It has human-machine interface, digital controlling of rpm, temperature, pressure, diesel fuel pump technical parameter and so on, and in pace with print. It easy and quick operates ,it's really human-machine dialog. This series test bench adopt high quality frequency conversing device and  cast  iron base supper size bed, and its distinguishing features are hi-stable character, hi-reliability, ultra-low-noise, perfect auto-protecting function and so on, It is advanced products.

Main function
1. Measurement of each cylinder delivery at any speed
2. Test point and interval angle of oil supply of injection pump.
3. Checking and adjust the mechanical governor.
4. Checking and adjusting the distributor pump.
5. .Experiment and adjusting of behavior of supercharging and compensatory device.
6. Measurement of oil return of distributing pump
7. Testing of the electromagnetic valve of distributor pump.(12V/24V)
8. Measurement of the internal pressure of distributor pump.
9. Checking of the advance angle of advance device.(on request)
10. Checking the sealing of injection pump body
11. Install tube of auto-sucking oil supply can check on oil supply pump(including VE pump.)
12. Checking the travel of stroke
13.oil lubricate(on request)
14.Cast iron base(on request)
15. Foced cooller(on request)

Technical characteristic

Adjustable cylinders numbers
Out power(Kw)
RPM
Rpm pre-set
Temperature control system
Positive pressure system
negative pressure system
12

5.5
7.5
11
15
18.5
0-4000


Air supply
DC power supply
internal pressure of VE pump
Oil return of VE pump
travel of tooth bar
Advanced angle
Capability with pump type




(On request)



(On request)
All in- line and rotary pump





Packaging & Shipping

 BC3000 diesel pump test bench check bosch denso injection pumpBC3000 diesel pump test bench check bosch denso injection pumpBC3000 diesel pump test bench check bosch denso injection pump



Company Information







We are the leading manufacturer in Diesel Injection Pump Test Bench and Turbo charger in CHINA, already sold more than 100 Countries, include EUI/EUP tester with Cam box, EDC VP37 tester, VP44 teser,RED4 EDC, HEUI tester, DENSO ECD-V3,V4,V5 pump tester,PT Cummins Pumps and Injectors tester, Common Rail injectors and Common Rail Pump tester( CRDI) and Turbo Charger, Spare parts(plunger, nozzle, head rotor, injector...) also different model tools for pump and injector repair.
