NTS200/EPS200 Commomn Rail Injector Testing Machine/CRDI Tester

NTS200/EPS200 Commomn Rail Injector Testing Machine/CRDI Tester thumbnail-1
NTS200/EPS200 Commomn Rail Injector Testing Machine/CRDI Tester thumbnail-2
NTS200/EPS200 Commomn Rail Injector Testing Machine/CRDI Tester photo-1
NTS200/EPS200 Commomn Rail Injector Testing Machine/CRDI Tester photo-2
US$ 3800.00 - 3800.00 MOQ: 1 Set
Key Specifications
Get Latest Price
Certification:
ce/iso
Applicable Models:
AUTO CAR
Place of Origin:
China
Contact Supplier Request Quote Chat Now
Taian Nantai Experimental Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Certification ce/iso
Applicable Models AUTO CAR
Place of Origin China
Brand Name NATNAI
Model Number EPS200
Warranty 1 Years
Product Description



EPS200 common rail injector test bench is our latest indepentent researched special device to test the performance of high-pressure common rail injector, controlled by industrial computer, Windows operating system. The oil quantity is measured by sensor and displayed on computer screen(Electronic fuel delivery system). All data can be searched and saved. It adopts BOSCH original common rail pump to provide 0~2000 bar for rail pressure. The rail pressure can be adjusted automatically, and it also provide pressure overload protect. It can test common rail injector of BOSCH, SIEMENS, DELPHI, DENSO. Advanced technology, steady performance, precise measurement and
 >>>CHARACTERISTIC
1. Controlled by industrial computer in real time, Windows operating system.
2. Oil quantity is measured by sensor and displayed on 10.4'' tactile  LCD screen;
3. More than 700 kinds of injecotors data can be searched and used.
4. It is installed BOSCH common rail pump to provide 0~2000 bar
5. Rail pressure can be tested in real time,
6. Provide pressure overload protect
7. Pulse and frequency of the injector can be adjusted.
8. Injection time can be set.
9.  Protection function of short-circuit.
10. Precise measurement, easy operation, low noise.
11.Frequency converter inside to keep the RPM.
 >>>FUNCTION
1.Test injector brands:BOSCH, SIEMENS, DELPHI, DENSO.
   Piezo injector testing(option function)
2. Test 1 piece of injector.
3. Test the Leakage performance of common rail injector.
4. injection oil quantity and back oil quantity(pre-injection, Idling, emissions, full load)
5. Electronic fuel delivery measuring,  automatic testing and detection.
6. Data can be searched and saved.
>>>TECHNICAL PARAMETER
1. output power:1.5KW
2. power voltage:220V 1phase
3. motor speed: 0-3000RPM
4. Oil pressure:0-2000bar
5. flow measure range: 0-600ml/1000times
6. flow measurement accuracy: 0.1ml
7. temperature control range: 40+-2
Packaging & Shipping

 NTS200/EPS200 commomn rail injector testing machine/CRDI testerNTS200/EPS200 commomn rail injector testing machine/CRDI tester

Company Information





we already sold more than 100 Countries, include EUI/EUP tester with Cam box, EDC VP37 tester, VP44 teser,RED4 EDC, HEUI tester, DENSO ECD-V3,V4,V5 pump tester,PT Cummins Pumps and Injectors tester, Common Rail injectors and Common Rail Pump tester( CRDI) ,Gasoline pumps and injectors tester and cleaner, Turbo Charger, and Spare parts(plunger, nozzle, head rotor, injector...) also different model tools for pumps and injectors repair. Hope to cooperate with you.





We are the leading manufacturer in Diesel Injection Pump Test Bench and Turbo charger in CHINA, already sold more than 100 Countries, includeEUI/EUP tester with Cam box, EDC VP37 tester, VP44 teser,RED4 EDC, HEUI tester, DENSO ECD-V3,V4,V5 pump tester,PT Cummins Pumps and Injectors tester,Common Rail injectors and Common Rail Pump tester( CRDI) and Turbo Charger, Spare parts(plunger, nozzle, head rotor, injector...) also different model tools for pump and injector repair.
