CRS300 common rail system test bench
- 10000 Set / Sets per Month
- qingdao
- T/T Credit Card
- Professional universal auto diagnostic scanner FCAR F3-G Car & Trucks Universal Diagnostic Scanner
- Hot Sale Original vehicle diagnostic equipment Fcar F3-G professional car and truck universal car diagnostic tool
- Universal Truck Diagnostic Tool fcar F3-G diesel and gasolin car diagnostic scanner for Japan,korea,Europe,America Cars
- Original Multi-functional English/Russian Version Fcar Universal truck diagnostic tool 24V diesel truck diagnostic scanner
- used car diagnostic scanner F3-G Global Car and Truck Diagnostic Scanner
- Original Fcar F3-G Automotive Diagnostic Scanners for 12V+24V Cars and Heavy duty trucks
Product Details
Voltage: | 220v | Certification: | CE/ISO | Applicable Models: | AUTO CAR |
Place of Origin: | China | Brand Name: | NANTAI | Model Number: | CRS300 |
Warranty: | 1 Years |
Product Description
Specifications
CRS300 common rail system test bench
CRS300 common rail pump and common rail injector test bench
CRS300 common rail system universal testing machine
*can test PE/EM injectors and CR pump
*pump brand:BOSCH DENSO DELPHI SIEM
- CRS300 common rail system universal testing machine is on sale by direct manufacture with low price and high quality
- >>>FUNCTION
- The function of the tester for CR high pressure pumps is to provide the desired signal to drive the solenoid in the pump being tested.
- High pressure CRS300 CRS-A common rail system tester can used for testing following pumps: BOSCH CP1,CP2,CP3,DELPHI, SIEMENS, DENSO HP2 AND HP3.
- It has the functions to test the Electromagnetic injectors.
- It also can test 6 common rail injectors in one time.
- >>> DESIGN FEATURE
- 1. Modulated driving signal to ensure the safety of the solenoid of the CR pump
- 2. Adjustable duty cycle for the driving signal
- 3. Short circuit protection for the output circuitry of the solenoid driving signal
- 4. Measure and LCD display rail pressure
- 5. To test if the CR injector is still function, To connect a CR injector to a high pressure fuel source by a high pressure fuel line and to the CR tester by harness. The tester is set to continuous injection mode. The CR injector is in normal condition, if it is capable to inject fuel under the driving signals by the tester.
- 6. To test injector spray atomization, To connect a CR injector to a high pressure fuel source by a high pressure fuel line and to the CR tester by harness. The tester is set to single injection mode to allow observing the nozzle spray pattern to judge if the nozzle is normal or orifice plugged.
- 7. Checking the Injectors return oil and injection oil.
- 8.CRS300 is computer system, it include common rail data inside.
- >>>MAIN TECHNICAL PARAMETERS
1. Injection open pressure:
Control accuracy: stage regulator
2. Injection open frequency:
Control range: 0-1000HZ
Control accuracy: 1HZ
3. Injection open hold time
Control range: 0-65535us
Control accuracy: 1us
4. Delivery counts
Control range: 0-1000
Control scope: 24V, 80V, 150V,
Control accuracy: 1times
5. Pump model :CP1,CP2,CP3,HP0
6. Fuel pressure control
Control range: 0-200Mpa
Control accuracy: 1Mpa
Control way: PID
7. Power:220V
8. Work temperature: 0-40°C
9. Relative humidity: 20-90%RH
standard export package
one year warranty
We are the leading manufacturer in Diesel Injection Pump Test Bench and Turbo charger in CHINA, already sold more than 100 Countries, include EUI/EUP tester with Cam box, EDC VP37 tester, VP44 teser,RED4 EDC, HEUI tester, DENSO ECD-V3,V4,V5 pump tester,PT Cummins Pumps and Injectors tester, Common Rail injectors and Common Rail Pump tester( CRDI) and Turbo Charger, Spare parts(plunger, nozzle, head rotor, injector...) also different model tools for pump and injector repair.
