Bosch common rail test bench CR3000A-708,common rail test bench

Specifications

Bosch common rail test bench CR3000A-708,common rail test bench

cr3000a-708 is the professional test bench which is used for testing common rail system, can finish the high-pressure common rail system





  Optional Fuction:

 1,One flow sensor(Injection,return oil.turn test)



 2,Two Flow Sensors(Recommend,test fast,Injection,return oil ,test at the same time)

 3,Weight Sensor(Many injectors can tested at the same time,Test easily and quickly,Low requirements on temperature and oil quality)



 4,DRV Valve And Pump Delivery Sensor,Used in CR PUMP Testing

 5,Can Test Denso HP0 pump

6,Can Test Bosch,Siemens piezo Injectors

 7,With BOSCH CP1 PUMP

 8,Injectors Mounting bracket, convenient and reliableinjectorclamping

 CR3000A COMMON RAIL TEST BENCH is the professional test bench which is used for testing common rail system, can test common rail pump,common rail injector at same time.
1,Pump testing: pump delivery, pressure,PVC working status, leakage of itself,
2,Injector testing: leakage, injection oil quantity and back oil quantity(pre-injection,Idling, emissions, full load)
3,it can test pressure sensor,and DRV valve
4. Supports system: BOSCH,DELPHI,DENSO,SIEMENS
5. Testing data inside( pump and injector)
6. Electronic fuel delivery measuring,  automatic detection.

Technical parameters
1.Motor power: 7.5KW, 11KW, 15KW, 18.5KW
2. Electronic power: 3 PHASE 380V or 3 PHASE 220V
3. Motor speed: 0-4000RPM
4. Presure adjustment: 0-2000bar
5. Flow testing range: 0-600ml/1000times
6.Flow measurement accuracy:0.1ml
7. Temperature range: 40+-2
8. Cooling system: fan or forced cooling
