Specifications
best quality,best price, best service
It has the function to test the electromagnetic injectors. It also can test 6 common rail injectors in one time.
Design Features
Modulated driving signal to ensure the safety of the solenoid of the CR pump;
Adjustable duty cycle for the driving signal;
Short circuit protection for the output circuitry of the solenoid driving signal;
Measure and LCD display rail pressure;
To test if the CR injector is still function, to connect a CR injector to a high pressure fuel source by a high pressure fuel line and to the CR tester by harness. The tester is set to continuous in injection mode. The CR injector in normal condition, if it is capable to inject fuel under the driving signals by the tester.
To test injector spray atomization, to connect a CR injector to a high pressure fuel line and to the CR tester by harness. The tester is set to single injection mode to allow observing the nozzle spray pattern to judge if the nozzle is normal or orifice plugged.
Checking the injection return oil and injection oil.
Technical parameters
- Fuel injector open voltage
Control range: 12v, 80v, 150v
Control accuracy: phase adjustment
- Injector opening frequency
Control: 0-1000HZ
Control accuracy: 1HZ
- Fuel injector hold time
Control: 0-65535us
- Delivery oil count
Control: 0-1000 times
Control accuracy: 1 times
- Fuel pressure control
Control: 0-2000bar
Control accuracy: 1bar
