NT815 Common Rail Test Bench CR Tester Cr-nt815/a Common-rail Test Bench

NT815 Common Rail Test Bench CR Tester Cr-nt815/a Common-rail Test Bench thumbnail-1
NT815 Common Rail Test Bench CR Tester Cr-nt815/a Common-rail Test Bench thumbnail-2
NT815 Common Rail Test Bench CR Tester Cr-nt815/a Common-rail Test Bench thumbnail-3
NT815 Common Rail Test Bench CR Tester Cr-nt815/a Common-rail Test Bench photo-1
NT815 Common Rail Test Bench CR Tester Cr-nt815/a Common-rail Test Bench photo-2
NT815 Common Rail Test Bench CR Tester Cr-nt815/a Common-rail Test Bench photo-3
US$ 5,000 - 6,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Voltage:
380V/220V
Power:
7.5KW-22KW
Certification:
CE/ISO
Contact Supplier Request Quote Chat Now
Taian Nantai Experimental Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Voltage 380V/220V
Power 7.5KW-22KW
Certification CE/ISO
Applicable Models auto car
Place of Origin China
Brand Name nantai
Model Number nt815
Warranty 1 Years

CR-NT815/A common rail test bench suitable for testing Bosch(CP1,CP2,CP3 series), Denso (HP0,HP2,HP3,HP4 pump series), Simens, Delphi and common rail injector of these brands.



Main technical parameters:

1. Power: 11kw, 15kw optional

2. Oil pump rotation speed: 0-4000 rpm

3. Test rang of rail pressure: 0-2000bar

4. Test precision of rail pressure: ±0.5Mpa

5. Test precision of flow sensor: 0.5%

6. Temperature of test oil:40±2°C

7. Filter precision of test oil: less than 5μ

8. Capacity of heavy tank: 80L

9. Dimension: 1780X900X1800MM

10. Aggregate weight: 1000KG

11. Electricity: 380V, 50Hz, 3 phase or 220V, 60 Hz, 3 phase



Functions:

1. Full-automatically test the common rail pumps:

         Injection and return

         Pump chamber pressure

         Oil supply pressure,

         Sealing performance

         Performance of measuring unit ZME control valve,

2. Full-automatically detect injectors during pilot injection and main injection

         Injection and return fuel delivery

         Equipped flow sensor for flow monitoring,

3. Test EUI and EUP through fixture and additional system.

4. Test kinds of electronic high pressure pump such as VP37 VE37 by additional systems.

5. Windows system and humanized operation, user can add data by himself, keep printed data and customer information.

6. Multi-machine network and remote control.



Equipment Characteristic:

1. High degree automation: Automation applied in both product detection and machine own operating.

2. Import configuration takes up 70% of equipment cost, domestic flow sensor is equipped to realize accurate measurement of flow.

3. Original common rail system specially used in Bosch test bench can realize accurate control of rail pressure via ZME valve and DRV valve.

4. Compact universal test bench can successively test 6 oil injectors in one setup.

4. Remote monitoring is convenient for service and software upgrading.

Packaging & Shipping

 NT815 common rail test bench CR tester cr-nt815/a common-rail test benchNT815 common rail test bench CR tester cr-nt815/a common-rail test benchNT815 common rail test bench CR tester cr-nt815/a common-rail test benchNT815 common rail test bench CR tester cr-nt815/a common-rail test bench

Company Information



Main products include:  1. Diesel engine parts (nozzle. plunger. delivery valve. head Rotor. injector. fuel pump and other accessories)

2.Injection pump test bench

3.auto tools

4 Auto parts

5. special vehicles

6 . Turbocharger.......      Production process using advanced computer control and digital display systems, production technology. strong technical force High quality, high technical performance, with micro-controller and digital functions. Products are sold  more than 100 countries and regions of all world .





We are the leading manufacturer in Diesel Injection Pump Test Bench and Turbo charger in CHINA, already sold more than 100 Countries, include EUI/EUP tester with Cam box, EDC VP37 tester, VP44 teser,RED4 EDC, HEUI tester, DENSO ECD-V3,V4,V5 pump tester,PT Cummins Pumps and Injectors tester, Common Rail injectors and Common Rail Pump tester( CRDI) and Turbo Charger, Spare parts(plunger, nozzle, head rotor, injector...) also different model tools for pump and injector repair.



Manager: Jun gang hou

Mobile: +86-15864752393

QQ: 87982354

Skype:  taianchina@

WhatsApp/WeChat/Viber: +86-15864752393

E-mail:  commonrail@

thanks for your attention!!

wish our cooperation!!
