Help CenterCRS200 COMMON RAIL SYSTEM TESTER
Related Products
-
EPS205 , DTS205, NTS205 COMMON RAIL INJECTOR TEST BENCHUS$ 3,000 - 4,000MOQ: 1 Set -
CRDI TEST BENCH DTS200 EPS200 NTS200US$ 3,000 - 4,000MOQ: 1 Set
-
Common Rail Injector Tester Test Bench Test Stander HEUI Test BenchUS$ 5,000 - 6,000MOQ: 1 Set
-
2016 The Hot Sale and Prime Quality of CRS708 Common Rail Injector Pump Test BenchUS$ 5,000 - 6,000MOQ: 1 Roll
-
Common Rail Injector Testing Machine CRS708 Bosch Eps 708 Common Rail Test BenchUS$ 5,000 - 6,000MOQ: 1 Set
The function of the tester for CR high pressure pumps is to provide
the desired signal to drive the solenoid in the pump being tested. CRS200
common rail Tester can used for testing following pumps: BOSCH
CP1CP2CP3SIEMENS, DENSO HP2 AND HP3. It has the functions to test
the Electromagnetic and Piezoelectric injectors.
It also can test 6 common rail injectors in one time.
Design Features
* Modulated driving signal to ensure the safety of the solenoid of the CR
pump
* Adjustable duty cycle for the driving signal
* Short circuit protection for the output circuitry of the solenoid driving
signal
* Measure and LCD display rail pressure
* To test if the CR injector is still function, To connect a CR injector to a
high pressure fuel source by a high pressure fuel line and to the CR tester by
harness. The tester is set to continuous injection mode. The CR injector is in
normal condition, if it is capable to inject fuel under the driving signals by
the tester.
* To test injector spray atomization, To connect a CR injector to a high
pressure fuel source by a high pressure fuel line
and to the CR tester by harness. The tester is set to single injection mode to
allow observing the nozzle spray pattern to judge if the nozzle is normal or
orifice plugged.
* Checking the Injectors return oil and injection oil.
Main products include:
1, Diesel engine parts (nozzle, plunger, delivery valve, head Rotor, injector, fuel pump and other accessories) 2 Injection pump test bench 3 auto tools 4 Auto parts 5, special vehicles 6 , Turbocharger.......
We are the leading manufacturer in Diesel Injection Pump Test Bench and Turbo charger in CHINA, already sold more than 100 Countries, include EUI/EUP tester with Cam box, EDC VP37 tester, VP44 teser,RED4 EDC, HEUI tester, DENSO ECD-V3,V4,V5 pump tester,PT Cummins Pumps and Injectors tester, Common Rail injectors and Common Rail Pump tester( CRDI) and Turbo Charger, Spare parts(plunger, nozzle, head rotor, injector...) also different model tools for pump and injector repair.
