2015 HOT 10G Anti-vibration 4-PIN Connection DC12V PAL NTSC 600tvl 6 Infrared Light Night Vision Camera in Rear View System
Key Specifications:
- Waterproof: IP69K approved
- Wider viewing angle up to 120 degrees
- Nightvision distance: approx. 5 m (6 infrared lights)
- Day / Night sensor for automatic adjustment
| Image Device: | 1/3'' SHARP RJ2365 760H CCD |
Total Number Of Pixels: |
||
| TV System: | PAL / NTSC | Sync. System: | Internal | |
| Effective Pixels: |
PAL: 752 (H) × 582 (V) / NTSC: 768 (H) × 494 (V) |
Resolution: | 600 TV Lines | |
| Total Number Of Pixels: | Microphone: | Yes | ||
| Minimum Illumination: |
0.01 Lux / F1.0, B/W: 0.001 Lux / F1.0 |
BLC: | Auto | |
| Video Output: | Composite Signal (1.0 Vp-p, 75 Ohm ) | AGC: | On/off | |
| White Balance: | Auto/ATW1/ ATW2/AWC-SET/MANUAL | |||
| S/N Ratio: | Better than 50 dB(AGC OFF) | |||
| Electronic Shutter: | AOTO:1/50-1/100,000 Sec. / 1/60-1/100,000 Sec. | |||
| Day / Night : |
Color,B/W(IR SMART), AUTO ( Level Adjust ) , EXT |
|||
| Mirror | ON/OFF | |||
| D-WDR | ON/OFF | |||
| 2D-DNR | ON/OFF | |||
| Back Light Comp | ON/OFF | |||
| Current Consumption: | Max. 90 mA | |||
| Power Supply: | DC 12 V | |||
| Connection: | 4 PIN | |||
| Anti-vibration: | 10 g | |||
| Operating Temperature: | -20°C~70°C, RH 95% MAX. | |||
| Storage Temperature: | -40°C~80°C, RH 95% MAX. | |||
| Lens: | 2.8 mm, 3.6 mm Optional | |||
PIC :
Related Cameras:
Mini Camera
Mini Wifi Hidden Reverse Camera System
Dual Lens Camera
Shivision Co., Ltd. ,
located in Tianhe District, Guangzhou, is a high-tech enterprise engaged in researching, developing, manufacturing and marketing vehicle rear vision products and surveillance products. Being in this field for more than 10 years, our company has been bringing in advanced manufacturing facilities, cutting-edge technology, and high-quality professional talents. The company has independently developed a series of intelligent cameras, digital LCD, video signal wireless processing system, image processors, and video recorders, etc.
Our company insists on "Independent R&D" and "Customer Oriented" as the business philosophy. We maintain advanced innovation ability, and keeps strict quality control of products. Through years of effort, our company has gained recognition and reputation from the majority of customers;the products are exported to overseas.
We have established trade relations with more than 150 countries, and the export rate has reached more than 95%. In addition, the company has been certified with the highest international level of quality management system in auto industry ISO/TS16949:2009, and we are also in strict accordance with the EU ROHS standard during manufacturing. Meanwhile, a variety of our products have reached the highest waterproof rating of IP69K, and approved with CE, FCC, and EMARK, etc. Besides, our company has won 4 Design Patent, 2 Utility Model Patent, and 7 Software copyright, which enable us to become one of the world's largest suppliers of rear view products in the world.
Our main market is North America and Western Europe .
