Car Reversing Aid Support Network Remote Monitoring Anti-viabration Car Surveillance Camera for Vehicle
Key Spec :
- HD 720P
- 1/4" 1.0megapixel CMOS sensor
- H.264 HighProfile
- Support POE Power Supply Optional
- Aluminum alloys Shell
- IP68
| Specification | HD 720P | ||||
| Operating System | Embedded LINUX,Haisi Series Hi3516C DSP | ||||
| Image Sensor | 1/4" 1.0 megapixel CMOS sensor | ||||
| Effective Pixel | 1280(H)*720(V) | ||||
| Electronic Shutter | 1/50(1/60)s~1/100,000s | ||||
| Signal System | PAL/NTSC | ||||
| Video Compression |
H.264 HighProfile, Support JPEG photograph, Support dual stream 0.1M~6Mpbs ADJ;Support Frame Rate 1~30fps ADJ; |
||||
| Video Bite Rate | 32 Kbps~8Mbps | ||||
| Dual Stream | Main Stream:1280*720;Second Stream:704*576; | ||||
| Frame Rate |
50Hz:25fps 1280*720) 60Hz:30fps (1280*720) |
||||
| Min. Illumination |
Color:0.5Lux @(F1.2,AGC ON) B/W:0.08Lux @(F1.2,AGC ON) 0 Lux with IR |
||||
| Image settings | Saturation, Brightness, Contrast adjustable through Client software or web server | ||||
| Ethernet | RJ-45 (10/100Base-T) | ||||
| Network Protocols | TCP/IP, HTTP, SMTP,DNS, DDNS, DHCP, FTP, NTP, PPPOE, UPNP etc. | ||||
| Lens | 2.8mm | ||||
| Day/Night | IR-cut filter with auto switch | ||||
| Intelligent Alarm | Motion detect,Video loss,Network disconnection,IP address conflict,Storage full,Storage error | ||||
| ONVIF | YES | ||||
| Mobile monitor | Support mobile monitor(iPhone, Android) | ||||
| Client-side | Provide web, CMS, center manage software (MYEYE), and SDK for development | ||||
| Power Supply | DC12V | ||||
| Protection Range | IP68 | ||||
| Operating Environment | -10°C ~+60°C, 10%-90% | ||||
| IR distance | 10-25m | ||||
PIC:
Wireless Reversing System Kit :
7 Inch 2.4GHz Digital Wireless Camera System
9 Inch Digital Wireless Camera System
Shivision Co., Ltd. ,
located in Tianhe District, Guangzhou, is a high-tech enterprise engaged in researching, developing, manufacturing and marketing vehicle rear vision products and surveillance products. Being in this field for more than 10 years, our company has been bringing in advanced manufacturing facilities, cutting-edge technology, and high-quality professional talents. The company has independently developed a series of intelligent cameras, digital LCD, video signal wireless processing system, image processors, and video recorders, etc.
Our company insists on "Independent R&D" and "Customer Oriented" as the business philosophy. We maintain advanced innovation ability, and keeps strict quality control of products. Through years of effort, our company has gained recognition and reputation from the majority of customers;the products are exported to overseas.
We have established trade relations with more than 150 countries, and the export rate has reached more than 95%. In addition, the company has been certified with the highest international level of quality management system in auto industry ISO/TS16949:2009, and we are also in strict accordance with the EU ROHS standard during manufacturing. Meanwhile, a variety of our products have reached the highest waterproof rating of IP69K, and approved with CE, FCC, and EMARK, etc. Besides, our company has won 4 Design Patent, 2 Utility Model Patent, and 7 Software copyright, which enable us to become one of the world's largest suppliers of rear view products in the world.
