Best 4CH Mobile DVR in CCTV DVR
4 channels mobile Features:
| Operating system | Embedded LINUX operating system | |||
| System resources | Multiplex real time synchronous record, multiplex real time playback, multiplex and multi-people network operation, USB backup |
|||
| Operating interface | 16-bit true color graphic menu operation interface, support mouse action | |||
| Image display | 1/4 image display | |||
| Video standard | PAL(625TVL,50f/s);NTSC(525TVL,60f/s) | |||
| Image coding | H.264(Main Profile); JPEG screenshot | |||
| Monitoring quality | Monitor: D1 | |||
| Playback quality | D1/Half-D1/CIF/QCIF | |||
| Code capacity | 4xD1 real time | |||
| Decode capacity | 2xD1 real time | |||
| Motion detection | 392(22*18) surveyed areas available for each image; | |||
| multi-level sensitivity | ||||
| Audio compression | G711A | |||
| Voice talk back | Support | |||
| Video mode | Manual> alarm> dynamic detection> timing | |||
| Local playback | Synchronous playback of selected cameras(Camera1-4) | |||
| Video retrieval | point-in-time retrieval, date retrieval, event retrieval and channel retrieval | |||
|
Occupied disk space per channel |
Video: CIF 4~5G/day*channel, D1 16~20G/day*channel; | |||
| Audio: 691.0M/day*channel | ||||
| Image storage | Local hard disk, network, SD card | |||
| Backup pattern | Network backup, USB mobile HDD, USB record, SATA record, SD card | |||
| Video input | 4 inputs | |||
| Video output | 1BNC output(1.0Vp-p,75Ω) | |||
| Audio input | 4 inputs | |||
| Audio output | 1 RCA output(200-3000mV,5K) | |||
| Alarm input | 8 inputs( multiplex vehicle signal) | |||
| Alarm output | 1 output | |||
| Network interface | RJ45 10M/100M Self-adaption toEthernet port | |||
| PTZ control | 1 RS485 interface | |||
| USB interface | 1 USB interface ( multiplex WIFI interface, switchable) | |||
| SD card | Support double SD cards | |||
| (Maximum 64 G. support recording, redundancy recording, backup and screenshot etc.) | ||||
| GPIO signal | Support speed signal, turn light signal, braking signal etc. inputs; support vehicle information SOD superposition and storage etc. |
|||
| GPS module | Onboard GPS module, support GPS information superposition, timing etc. | |||
| WIFI module/ 3G module | Onboard WIFI module (support RT3070 series module, multiplex USB interface), support equipment’s active registering and reporting to the platform |
|||
| (alternative) |
Onboard 3G module, support EVDO,WCDMA and TD-SCDMA, support equipment’s active registering and reporting to the platform; perfect narrowband transmission strategy to ensure the stability and fluency of 3G network media stream |
|||
| Others | Support power-on delay and power-off delay; support fixed timing starting up and shutdown function |
|||
| Player | Player specially for In-vehicle, support Google Map to record driving routes of vehicles; support display of vehicle information |
|||
| Platform software | Support active registration mode, dispense with port mapping and thoroughly solve the connecting problem of 3G network |
|||
| Supporting SDK | Provide perfect SDK for secondary development and integration | |||
| Power supply | Wide voltage input of 6V to 40V | |||
| Power consumption | <10W(Hard Disk excluded) | |||
| Operating temperature | 0℃-+55℃ | |||
| Operating humidity | 10%-90% | |||
Shivision Co., Ltd. ,
located in Tianhe District, Guangzhou, is a high-tech enterprise engaged in researching, developing, manufacturing and marketing vehicle rear vision products and surveillance products. Being in this field for more than 10 years, our company has been bringing in advanced manufacturing facilities, cutting-edge technology, and high-quality professional talents. The company has independently developed a series of intelligent cameras, digital LCD, video signal wireless processing system, image processors, and video recorders, etc.
Our company insists on "Independent R&D" and "Customer Oriented" as the business philosophy. We maintain advanced innovation ability, and keeps strict quality control of products. Through years of effort, our company has gained recognition and reputation from the majority of customers;the products are exported to overseas.
We have established trade relations with more than 150 countries, and the export rate has reached more than 95%. In addition, the company has been certified with the highest international level of quality management system in auto industry ISO/TS16949:2009, and we are also in strict accordance with the EU ROHS standard during manufacturing. Meanwhile, a variety of our products have reached the highest waterproof rating of IP69K, and approved with CE, FCC, and EMARK, etc. Besides, our company has won 4 Design Patent, 2 Utility Model Patent, and 7 Software copyright, which enable us to become one of the world's largest suppliers of rear view products in the world.
Certification
Desktop
Production Line
Office
Our main market is North America and Western Europe .
