1.8m, 1.9m uv Led Printing Machine, DX5 Head uv Printer

1.8m, 1.9m uv Led Printing Machine, DX5 Head uv Printer thumbnail-1
1.8m, 1.9m uv Led Printing Machine, DX5 Head uv Printer thumbnail-2
1.8m, 1.9m uv Led Printing Machine, DX5 Head uv Printer thumbnail-3
1.8m, 1.9m uv Led Printing Machine, DX5 Head uv Printer thumbnail-4
1.8m, 1.9m uv Led Printing Machine, DX5 Head uv Printer photo-1
1.8m, 1.9m uv Led Printing Machine, DX5 Head uv Printer photo-2
1.8m, 1.9m uv Led Printing Machine, DX5 Head uv Printer photo-3
1.8m, 1.9m uv Led Printing Machine, DX5 Head uv Printer photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, ECO-Solvent printer
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Deju Digital Technology (Guangzhou) Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Other, ECO-Solvent printer
Place of Origin Guangdong, China
Brand Name Deju
Model Number DJ-1800S
Usage Paper Printer
Automatic Grade Automatic
Voltage 220v(±10%),
Gross Power 700W
Dimensions(L*W*H) 2.7 x 0.86 x 1.28 m
Weight 300KG
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

1.8m uv roll to roll printer with  DX5 head



1.8m, 1.9m uv led printing machine, DX5 head uv printer









 High Productivity



 Support double DX5 print head

Equipped with automatic print head maintenance station

Positive ink supply system with 1500ml/color capacity ink tank

Perfect Color Presentation

Perfect brushless Servo Motor with DSP digital controlling technology

Original Industrial HIWIN non-noise linear rail

High resolution media feeding system, more accurate

Industrial vacuum table keep high resolution printing quality

 High-tech on printing control, less ink consumption



Specification:

Model

DJ-1800S

DJ-2000D

DJ-3200D

Resolution

Up to 1440dpi Visual Resolution

Printhead

Piezo Technology DX5

Print head number

1 PC

2 PCS

2 PCS

Printing Width

1650mm

1850mm

3200mm



Printing Speed(sqm/h)

Production : 14

Standard: 13

High Resolution : 10

Production :  32

Standard: 26

High Resolution : 22

Production : 48

Standard: 40

High Resolution : 33

Ink Type

uv ink

Ink Supply System

Positive ink supply system with cleaning function

Ink tank capacity: 1500ml/color

Color

Double CMYK

Media Width

1700mm

1900mm

3200mm

Media Thickness

 1.5mm (1.5mm-5mm adjustable)

Media Roll Diameter(I/D)

55mm or 76mm/ <200mm

Maximum Media Weight

100KG

100KG

150KG

Media Type

Vinyl, Flex Banner, Mesh, One Way Vision, Paper, Textile, Wall Paper, Coated Banner, Canvas, Film, Lint-free Cloth, Photo Paper etc.

Data Communication

High speed USB2.0(480m/s)

Image data format

BMP, TIFF, EPS,PDF, AI, JPEG

Rip

Ultra Print V4.4 YIFANG Version

Operation environment

Power supply: 220v(±10%), >10A,single phase

(Temperature): 18°C-35°C

(Humidity): 40%-70%

Power Consumption

700W

700W

1200W

Machine Size (L x W x H)

2.7 x 0.86 x 1.28 m

2.98 x 0.86 x 1.28 m

4.36 0.86 x 1.28 m

Packing Size (L x W x H)

2.7 x 0.76 x 0.83 m

2.95 x 0.76 x 0.83 m

4.5 x 0.95 x 1.46 m

Gross Weight / Net Weight

300KG/225KG

340KG/420KG

840KG/750KG

 The exact configurations of equipment are subject to real machine

Motor

Perfect Brushless Servo Motor

Linear Rail

Original Industrial HIWIN non-noise linear rail

Heating System

Digital Control Pre & Back Heater

Media Feeding

Yes

Yes

Yes

Drying System

Optional

Yes

Yes

IR Drying System

Optional

Optional

Optional

Media Handling

Roll to roll handling

Take-up System

Optional: single/double driven automatic take-up



Future :

                 Positive ink supply system with 1500ml/color capacity ink tank









Original Industrial HIWIN non-noise linear rail

High resolution media feeding system, more accurate

 Packaging









 Our Services



1.It is free that customer can be trained in our factory.



2. Printing sample for free



3.Providing 1 year warranty.
