3200 Advertising Roll to Roll UV Printer, uv Roll Printing Machnine

3200 Advertising Roll to Roll UV Printer, uv Roll Printing Machnine thumbnail-1
3200 Advertising Roll to Roll UV Printer, uv Roll Printing Machnine thumbnail-2
3200 Advertising Roll to Roll UV Printer, uv Roll Printing Machnine thumbnail-3
3200 Advertising Roll to Roll UV Printer, uv Roll Printing Machnine thumbnail-4
3200 Advertising Roll to Roll UV Printer, uv Roll Printing Machnine thumbnail-5
3200 Advertising Roll to Roll UV Printer, uv Roll Printing Machnine photo-1
3200 Advertising Roll to Roll UV Printer, uv Roll Printing Machnine photo-2
3200 Advertising Roll to Roll UV Printer, uv Roll Printing Machnine photo-3
3200 Advertising Roll to Roll UV Printer, uv Roll Printing Machnine photo-4
3200 Advertising Roll to Roll UV Printer, uv Roll Printing Machnine photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, Paper Printer
Place of Origin:
Shanghai, China
Contact Supplier Request Quote Chat Now
Deju Digital Technology (Guangzhou) Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Other, Paper Printer
Place of Origin Shanghai, China
Brand Name DEJU
Model Number F3308
Usage Cloths Printer, Paper Printer, Other
Automatic Grade Automatic
Voltage AC,50HZ/60HZ 220v
Gross Power 3KW
Dimensions(L*W*H) 4420X1350X1400MM
Weight 650kg, 650Kg
Certification CE
After-sales Service Provided Engineers available to service machinery overseas



                            3200 Advertising roll to roll UV Printer



3200 Advertising roll to roll UV Printer, uv roll printing machnine











Technical advantages:

-----Ink detection alarm system



-----Use Vacuum Ink supply Systems.



-----High-power to the servo motor

-

----Print head height adjustment



-----Use imported UV-LED CURING LAMP



-----leg removable structure



1. Ink detection alarm system                                        3200 Advertising roll to roll UV Printer, uv roll printing machnine
When anyone ink barrel color ink is about to
run out, this system can point out what color22
ink you need to add ink.

2. Use Vacuum Ink supply Systems                                                     3200 Advertising roll to roll UV Printer, uv roll printing machnine
Use Vacuum Ink supply Systems that satisfy
with long time printing.













3. High-power to the servo motor                                   3200 Advertising roll to roll UV Printer, uv roll printing machnine
Original DELTA servo motor, with digital

 accurate driver, developed the running

accuracy of the machine.









4. Print head height adjustment                                                          3200 Advertising roll to roll UV Printer, uv roll printing machnine
Easy operating printhead height adjustment could

be used according to all kinds of media thickness

 and actual printing needs.














 5. leg removable structure                                                         3200 Advertising roll to roll UV Printer, uv roll printing machnine
Can place 12 leg removable printers to one 40’

 container = cut down the freight cost = cut down

 the incoming price













6.Use imported UV-LED CURING LAMP
Use international famous brand UV-LED curing                         3200 Advertising roll to roll UV Printer, uv roll printing machnine

 lamp.non-deformation, non-cracking, rapid

drying, long using life.





Technical Specifications



Model

F 3308

Top Resolution

180x720,240x720,180x1080,240x1080,
180x1440,240X1440

UV energy source

UV-LED CURING LAMP

Media printing width

3.2m(126 inch)

Speed

2pass 80m2/h 3pass 65m2/h 4pass 45m2/h

Color

C ,M,Y,K / C,M,Y,K, L C,LM (Optional)

Width

3.2m(126 inch)

Media handling

Roll to Roll

Media

aper / Advertising banner /PET/PC/ PVC / Adhensive vinyl and so on

Ink

UV LED curing Ink

Image format

TIFF/JPG/EPS/PDF/BMP

Working flow

Use photoprint with PRT format to print

RIP software

photoprint 12

Control station

Windows 2000 workstation / Windows XP / Vista /Window 7

Operation environment

Power Supply:AC,50HZ/60HZ 220v(10%)
Distortion:<0.5% Temperature:18°C~26°C Humidity:40%~70%

Dimension

4420X1350X1400MM

Weight

650Kg







3200 Advertising roll to roll UV Printer, uv roll printing machnine      3200 Advertising roll to roll UV Printer, uv roll printing machnine





                3200 Advertising roll to roll UV Printer, uv roll printing machnine





3200 Advertising roll to roll UV Printer, uv roll printing machnine 3200 Advertising roll to roll UV Printer, uv roll printing machnine
