Help Center1/4" CMOS(BYD) Color 700TVL Fishing Camera Kit With Built-in Rechargeable Battery
Related Products
-
Wifi 700tv Lines Rechargeable Uderwater HD Fishing CameraNegotiableMOQ: 10 Sets -
Built-in Rechargeale Lithium Battery Underwater Waterproof Cctv Fishing CameraNegotiableMOQ: 10 Sets
-
20m Cable Underwater Infrared Fish Finder CameraNegotiableMOQ: 1 Set
-
IP69 700TV Lines Underwater Fishing Camera for AnglerNegotiableMOQ: 10 Sets
-
DC12V IP69 Color CMOS Sensor 20m Underwater Fishing Camera for Fishing With Digital Signal WIFI Transmitter Quality Choice Most PopUS$ 80 - 96MOQ: 1 Set
Specifications
1/4" CMOS(BYD) Color 700TVL Fishing Camera2).Waterproof: IP69K
3)Built-in Rechargeable Battery
1/4" CMOS(BYD) Color 700TVL Fishing Camera with Built-in Rechargeable Battery
Application :
Features :
1).1/4" CMOS(BYD) 700TVL
2).Waterproof: IP69K
3).IEEE 802.11b/g/n, WEP /WPA1/WPA2
4). Built-in Rechargeable Battery
Data specifications
| C2101 | B0137BT | ||||
| Image Device: | 1/4" CMOS(BYD) CCD | Video input | CVBS | ||
| TV System: | PAL / NTSC | Transmitting distance | 30M,100m ( barrier-free) | ||
| Effective Pixels: | 720 x 480pixels / 720 x 576 pixels | Image Compression | H.264 + MJPEG | ||
| Sync. System: | Internal | VIDEO Record | Built-in TF-card | ||
| Resolution: | 700 TV Lines | WIFI Connect | LAN Peer to peer connection monitoring via Smart Phone(IOS device or Android) | ||
| Vertical Sync. Frequency: | 50 Hz / 60 Hz | Resolution | 720P(1280*720) VGA(640*480) | ||
| Video Output: | 1.0 vp-p, 75 Ohm | Delaying time | 300ms | ||
| Gamma Consumption: | 0.45 | Compression rate | 128Kbps~4Mbps | ||
| AGC: | Auto | Wireless Standard | IEEE 802.11b/g/n, WEP /WPA1/WPA2 | ||
| 2D-NR: | Digital Noise Reduction | Client Software | Shicloud | ||
| Electronic Shutter Speed: | 1/1 ~ 1/10,000s | Language | Chinese/English | ||
| S/N Ratio: | Better than 48 dB | Power (Max.) supply | DC 5V | ||
| White Balance: | Auto | Working temperature | -20°C~70°C.,Humidity 90% | ||
| BLC: | Auto | Storage Temperature | -30°C~80°C.,Humidity 90% | ||
| Current Consumption: | Max. 150 mA | Waterproof rating | IP69K | ||
| Power Supply: | DC 5V | Battery | 2500mA/3.7V | ||
| Connection: | 4 PIN Female | ||||
| Anti-vibration: | 10 g | ||||
| Operating Temperature: | -20°C~70°C , RH 95% MAX. | ||||
| Storage Temperature: | -40°C~80°C, RH 95% MAX. | ||||
| Lens: | f= 2.5 mm | ||||
| Lens Angle: | 90° | ||||
PIC :
Shivision Co., Ltd. ,
located in Tianhe District, Guangzhou, is a high-tech enterprise engaged in researching, developing, manufacturing and marketing vehicle rear vision products and surveillance products. Being in this field for more than 10 years, our company has been bringing in advanced manufacturing facilities, cutting-edge technology, and high-quality professional talents. The company has independently developed a series of intelligent cameras, digital LCD, video signal wireless processing system, image processors, and video recorders, etc.
Our company insists on "Independent R&D" and "Customer Oriented" as the business philosophy. We maintain advanced innovation ability, and keeps strict quality control of products. Through years of effort, our company has gained recognition and reputation from the majority of customers;the products are exported to overseas.
We have established trade relations with more than 150 countries, and the export rate has reached more than 95%. In addition, the company has been certified with the highest international level of quality management system in auto industry ISO/TS16949:2009, and we are also in strict accordance with the EU ROHS standard during manufacturing. Meanwhile, a variety of our products have reached the highest waterproof rating of IP69K, and approved with CE, FCC, and EMARK, etc. Besides, our company has won 4 Design Patent, 2 Utility Model Patent, and 7 Software copyright, which enable us to become one of the world's largest suppliers of rear view products in the world.
