UV flatbed and roll to roll printer
Technical Specifications
Model |
FR2512 |
|
Color |
C, M, Y, K, Lc, Lm, White, Varnish |
|
Print head |
Konica 512/1024, Ricoh Gen4/Gen5 |
|
Number of Print head |
Up to 12 piece konica print head, Up to 8piece Ricoh head |
|
Printing Speed |
Up to 40m2/h(8 Print heads double 4 color) |
|
Max.material thickness |
Rigid materials<=120mm, Flexible media<=1mm |
|
Drying system |
UV mercury lamp |
|
Air draft |
4 air draft divisions adapt to the max working area dimension |
|
Media |
Glass, PMMA, acrylic, ceramic, Metal, Paper, Wood, Leather,Flex banner, Wallpaper, Car sticker, Soft film, PVC,etc |
|
Printing size |
Maximum Printing Area:
|
Rigid materials: 2680mm(width)*1220mm(depth) |
Flexible Media width:2500mm | ||
|
Maximum Material Size:
|
Rigid materials: 2700mm(width)*1330mm(depth) |
|
Flexible Media width:2500mm | ||
Ink |
UV Curing ink |
|
Outdoor life |
At least 3 years outdoor/10 years indoor |
|
Ink capacity |
2.5L drums, automatic ink control, non-stop and ink |
|
Ink supply system |
Auto negative ink supply |
|
Control system |
Windows 2000 workstation/ Windows XP/ Vista/ Windows 7 32bit RAM>=6G |
|
Power Supply |
6.5KW; AC, 50HZ/60HZ, 220V(+=10%)>15A |
|
Image format |
Tiff, JPEG, EPS |
|
RIP software |
Photoprint 10/Colorgate |
|
Dimensions (L x W x H) |
4830 x 2470 x 1580mm |
|
Package dimensions (L x W x H) |
5400*2200*1650mm & 3450*800*1050mm |
|
Net weigh t& Gross weight |
1550kg & 2280kg |
|
Safety certification |
CE certification |
|
Features
1.Ink system
1).Ink alarm system 2).White ink circulation 3).heating control for ink subtank
2. UV lamp system
3.Flatbed
1.Location pins mounted on table to load regular or irregular materials in right place, which help ensure same print starting point in X and Y direction for batch jobs.
2.4 stage vacuum control system that can print on different width media, the powerful vacuum
4.Carriage
1.Advanced print head anti-collision system
2.Adjust height of carriage by control panel, manual, software
5.Roller system
6. Electric System
7.Control Panel
8.Movement System
1.two servo motor for beam improving printing accuracy;
2.IGUS towline cable from Germany;
3.MEGADYNE synchronous belt from Italy.
9.Negative Pressure
negative pressure can be worked with power supply when machine power off.
Sample
