700 TVL CCD IR Anti-explosion Camera in CCTV Camera
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Shivision
Model Number:
CW669
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Waterproof CCD 700 TVL Night Vision Anti-explosion Camera in CCTV CameraNegotiableMOQ: 10 Pieces -
Waterproof Anti-explosion SONY 2megapixel CMOS Sensor IP CameraNegotiableMOQ: 1 Set
-
Waterproof IP69 DC12V 700TVL CCD Silvery Explosion Proof Anti-explosion Camera With IR 8~10mNegotiableMOQ: 10 Sets
-
100% Factory 700TVL CCD Explosion Proof 304 Stainless Steel Waterproof Anti-explosion Salty Proof Camera CCTV for Marine ShipUS$ 140 - 150MOQ: 1 Piece
-
100% Factory 700TVL CCD Explosion Proof 304 Stainless Steel Waterproof Vehicle Camera for Rear ViewUS$ 140 - 150MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Shivision
Model Number
CW669
Sensor
CCD
Technology
Infrared
Special Features
Waterproof / Weatherproof
Type
Other, Anti-explosion Camera
Specifications
700 TVL CCD Anti-explosion CameraBuilt-in 15M infrared lamp
Installation angle can adjustable
Product Description
700 TVL CCD IR Anti-explosion Camera
Application :
Tanker Monitoring Natural Gas Truck Rear View
Features :
- Anti-explosion Camera
- 304 stainless steel molded in integral with polished finish
- Anti-explosion, waterproof, dustproof, anti-shock, small size
- Installation angle can adjustable
- Built-in 15-meter infrared lamp for night
- Mainly used in inflammable,explosive workplace and transport vehicles for inflammables
Data specifications
| Model | CW669 | |||
| Video | Image Device | 1/3” SONY EXview HAD CCD II | ||
| TV System | PAL | NTSC | ||
| Effective Pixels | 976(H)*582(V) | 976(H)*494(V) | ||
| Sensing Area | 5.58mm×4.67mm | |||
| Scanning System | 2:1 Interlace | |||
| Sync. System | Internal | |||
| Resolution> | 700TV Lines | |||
| WDR | YES | |||
| ATR | YES | |||
| 2D noise reduction | YES | |||
| Digital demist process | YES | |||
| Privacy mask | YES | |||
| Face detection | YES | |||
| Motion detection | YES | |||
| HLR(high light reduction ) | YES | |||
| OSD | supports 8 Languages | |||
| Horizontal Sync Frequency | 15.625 kHz | 15.734 kHz | ||
| Vertical Sync Frequency | 50 Hz | 60 Hz | ||
| Video Output | 1.0Vp-p, 75Ohm | |||
| Gamma Consumption | 0.45 | |||
| AGC | Auto | |||
| S/N Ratio | Better than 48dB | |||
| White Balance | Auto | |||
| Electronic Shutter | 1/60(NTSC)/1/50(PAL)~1/100,000 Seconds | |||
| BLC | Auto | |||
| Storage Temperature | –50℃ ~ 95℃, RH95%MAX. | |||
| Operating Temperature | –30℃~85℃ | |||
| Minimum Illumination | 0 Lux | |||
| Others | Power Supply | DC12V | ||
| Night vision distance | 8~10m | |||
| Anti-hazard classification | Exd II CT6 | |||
| Waterproof rating | IP69K | |||
| Image mode | Normal | |||
| Viewing Angle | 120° 92° 69° | |||
| Material quality | 304 Stainless steel | |||
| Dimension(mm) | Item size : (L*W*H) | |||
| Package size: (L*W*H) | ||||
| Weight | Item weight: | |||
| Package weight: | ||||
| Accessories | Anti-Explosion stack | |||
