100% Manufacturer DC 12V 24pcs LED Light CCD 700tvl IP68 Waterproof Stainless Steel Cameras for Rear Front Side View
Application :
Tanker Monitoring Natural Gas Truck Rear View
Features :
- SONY CCD 700TV Lines
- 1/3” SONY EXview HAD CCD II
- Waterproof rating:IP68
- Night vision distance:8~10m
- Material quality:304 Stainless steel
Data specifications
| Image Device | 1/3” SONY EXview HAD CCD II |
| TV System | PAL,NTSC |
| Effective Pixels | 976(H)*582(V) 976(H)*494(V) |
| Sensing Area | 5.58mm×4.67mm |
| Scanning System | 2:1 Interlace |
| Sync. System | Internal |
| Resolution | 700TV Lines |
| ATR | YES |
| 2D noise reduction | YES |
| Motion detection | YES |
| Horizontal Sync Frequency | 15.625 kHz/15.734 kHz |
| Vertical Sync Frequency | 50 Hz/60 Hz |
| Video Output | 1.0Vp-p, 75Ohm |
| Gamma Consumption | 0.45 |
| AGC | Auto |
| S/N Ratio | Better than 48dB |
| White Balance | Auto |
| Electronic Shutter | 1/60(NTSC)/1/50(PAL)~1/100,000 Seconds |
| BLC | Auto |
| Storage Temperature | –50℃~95℃, RH95%MAX. |
| Operating Temperature | –30℃~85℃ |
| Minimum Illumination | 0 Lux |
| Power Supply | DC12V |
| Night vision distance | 8~10m |
| Waterproof rating | IP68 |
| Image mode | mirror/normal (optional) |
| Viewing Angle | 92° |
| Material quality | 304 Stainless steel |
