3.2m textile printing machine with two DX5 print head
Features:duuuu
1.High Productivity.
2.Support Two DX5 print head.
3.Equipped with automatic print head maintenance station.
4.Positive ink supply system with 1500ml/color capacity ink tank.
5.Perfect Color Presentation.
6.Perfect brushless Servo Motor with DSP digital controlling technology.
7.Original Industrial HIWIN non-noise linear rail.
8.High resolution media feeding system, more accurate.
9.Industrial vacuum table keep high resolution printing quality.
10.High-tech on printing control, less ink consumption.
Specification:
Model |
3200T |
|
Resolution |
Up to 1440dpi Visual Resolution |
|
Printhead |
Two piece DX5 print head |
|
Printing Width |
3200mm(125inch) |
|
Printing Speed(sqm/h) |
4Pass:38 6Pass:26 8Pass:18 |
|
Ink Type |
Sublimation Ink/Painted Ink |
|
Ink Supply System |
Positive ink supply system with cleaning function Ink tank capacity: 1500ml/color |
|
Color |
Double CMYK |
|
Media Width |
3200mm |
|
Media Thickness |
1.5mm (1.5mm-5mm adjustable) |
|
Media Roll Diameter(I/D) |
55mm or 76mm/ <200mm |
|
Maximum Media Weight |
150KG |
|
Media Type |
Textile, Fabric, Lint-free Cloth, Flag, Cotton, Polyester etc. |
|
Application |
flag, fabric cloth, polyester, pillow, shoes, chair coverings, table coverings,fabric sofa, beddings etc |
|
Data Communication |
High speed USB2.0(480m/s) |
|
Image data format |
BMP, TIFF, EPS,PDF, AI, JPEG |
|
Rip |
Ultra Print V4.4 Version/Photoprint/Maintop |
|
Operation environment |
Power supply: 220v(±10%), >10A,single phase (Temperature): 18°C-35°C (Humidity): 40%-70% |
|
Power Consumption |
1500W |
|
Machine Size (L x W x H) |
4540*1310*1200mm/ 420±15KG |
|
Packing Size (L x W x H) |
4700*1450*1350mm/ 550±15KG |
|
Motor |
Perfect Brushless Servo Motor |
|
Linear Rail |
Original Industrial HIWIN non-noise linear rail |
|
Heating System |
Digital Control Pre & Back Heater |
|
Media Feeding |
Equiped |
|
Drying System |
Equiped |
|
IR Drying System |
Equiped |
|
Take-up System |
Equiped: single/double driven automatic take-up |
|
|
3.2m Color fixation machine | ||
|
1. Unique cloth electricity sub-cut function; 2. Cloth crease function; 3. Automatic synchronization function rewinding; 4. Advanced temperature control system; 5. Speed adjustable function. |
|
| Specification | ||
| Maximum media width | 3200mm(125inch) | |
| Heating Power | 9.8KW | |
| Speed | 5m-130m/h | |
| Heating temperature | 20℃-230℃ | |
| Power source | 50HZ—60HZ,AC380V |
|
| Total power | 10.5kw | |
| Machine Size | 3760*1380*945(mm) | |
| Weight | 580kg | |
Thank you for your reading, Welcome to your inquiry!
Name:James Liu Skype:dejutech04 Whatsapp/Mobile:0086-137-6077-3046
