large format DEJU H8 solvent printer
1. Main Features Of The Product
It's a roll to roll digital inkjet printer. Applied to a wide range of fields, such as banner,sticker,one way vision,wesh,photo paper,etc.
2.The details of our products
2.Technical advantages
1.LED lights help customer for better observing printing quality and color bar..
2.Printhead cleaning system is perfect designed for single or multiple printhead cleaning.
3.100W DC servo motor.equipped 1000 sting American Agilent decoder, with specialized control chip,frequency of signal 4, achieve the precise control of media stepper. RBI signal sampling adopting.
4.Four-in-one integrate temperature control with LED window is easy to set up expected temperature and maintain a constant temperature in a user-friendly operation.
5.Adjustable Automatic Media Feeding & Take-up System helps statisfy with stability.
6.we can place 6 printers into one 40’ container = save the freight cost = save the incoming price.
7.Machine precision control:All on the marble flat (6000mm±0.01mm) to have beeline check.
3. Technical Specification
| Machine Type | H8 Digital Inkjet Printer | |||
| Print Head | 8*KONICA512MN/14PL | 8*KONICA512LN/42PL | ||
| Print Mode | 360×1080dpi/3P | 360×1440dpi/4P | 180×720dpi/2P | 180×1080dpi/3P |
| Print Speed | 48m2/h | 35 m2/h | 80 m2/h | 55 m2/h |
| Print Width | 3300MM | |||
| Printer Interface | USB | |||
| Media Transmission | Roll to Roll | |||
| Data Transfer | Edge RIP while print/RIP post-print | |||
| RIP Software | ULTRAPRINT,PHOTOPRINT, MAINTOP | |||
| Heating System | Four-heating:Before printing,printing,print post,Ink heating | |||
| Cleaning System | Separation dual function of pressure and suction cleaning | |||
| Material Systems | (Sent/received)feeding standard to close material matching | |||
| Ink Types | C,M,Y,K four-color or C,M,Y,K,LC,LM 6-color solvent-based ink | |||
| Power Requirements | 220VAC±10%,<4A,50/60HZ/220VAC±10%,<16A,50/60HZ | |||
| Working Environment | Temperature:20°C~30°C,Humidity:40%~70% RH | |||
| Media Type | banner,sticker,one way vision,wesh,photo paper,etc. | |||
| Dimensions | (L×W×H)4500×1000×1450MM | |||
| NW/GW | 700kg/800kg | |||
4.After sales service :
*Lifetime warranty
sample
For more information ,welcome to contact me. Thanks for your reading!
Lucky Chen
Skype:dejutech02
Whatsapp:0086-18819364200
