3.2m Solvent Printer for Paper, Digital Paper Printer

3.2m Solvent Printer for Paper, Digital Paper Printer photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
GuangZhou
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Plate Type Flatbed Printer
Place of Origin Guangdong, China
Brand Name DEJU
Model Number DJ-HDA3300
Usage Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer, Other
Automatic Grade Automatic
Voltage 220v(±10%)
Dimensions(L*W*H) 4.57 x 0.88 x 1.65(M)
Weight 480KG
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Printing Width:3200m(126 inch)
High Resolution:Up to 1440dpi
High Printing speed:Up to 72sqm/h





3.2m solvent printer



 3.2m solvent printer for paper, digital paper printer





Technical advantages



1.LED lights help customer for better observing printing quality and color bar.



2.Printhead cleaning system is perfect designed for single or multiple printhead cleaning.



3.100W DC servo motor.equipped 1000 sting American Agilent decoder, with specialized



control chip,frequency of signal 4, achieve the precise control of media stepper. RBI signal



sampling adopting.



4.Four-in-one integrate temperature control with LED window is easy to set up expected



temperature and maintain a constant temperature in a user-friendly operation.



5.Adjustable Automatic Media Feeding & Take-up System helps statisfy with stability.



6.we can place 6 printers into one 40’ container = save the freight cost = save the incoming price.



7.Machine precision control:All on the marble flat (6000mm±0.01mm) to have beeline check.





Technical Specifications

Model

HDA3300

Color

 C ,M,Y,K (4C)

Printhead

KM512/XAAR382/XAAR128

Top Resolution

UP TO 1440dpi

 Speed

2pass 72m2/h  3pass 58m2/h   4pass 30m2/h (8 PCS KM512LN printhead)

Media

Paper/Advertising banner/PVC/Adhensive vinyl and so on

Mediaprinting width

3.2m(126 inch)

Media handing

Roll to Roll

Image format

Tiff,Jpeg,Postscript3,EPS,PDF and so on

Ink

Solvent-based ink

Printing software

Photoprint 10 /Seeget/Ultraprint

Optional

1.Automatic printhead maintenance system (optional)

2.Media take-up system

3.Carriage up and down system

Dimensions

4.57 x 0.88 x 1.65(M)

Net & Gross

480kg & 500kg

Package dimensions

4.85 x 0.74 x 1.10 (M) (removable)

Control station

Windows 2000 workstation / Windows XP/Vista/Window7  32bit

Operation environment

Power Supply:,AC,50HZ/60HZ , 220v(±10%)>15A



Distortion:<0.5%  Temperature:20℃~30℃  Humidity:40%~70%

Safety Certification

CE certification



Samples

 3.2m solvent printer for paper, digital paper printer



3.2m solvent printer for paper, digital paper printer





3.2m solvent printer for paper, digital paper printer
