portable laser marking machine

Specifications

portable laser marking machine
Machine 1 year warranty
Fiber laser MTBF: 100000 hour
Easy operation, easy maintenance
Fib

portable laser marking machine

Fiber laser Marking Machine: small desk style 10W  Metal Laser Marking Machine on Sale



1.small size (600*600*680mm): saving your valuable space

2.light weight (net weight about 50kg): saving your freight

The weight of old desk fiber laser marking machine is above 80KG.



Application:



portable laser marking machine

LMT2010 series fiber laser marking machine is suitable for metal laser marking: stainless steel, high-grade steel, steel, carbon steel, copper, iron, ferrous metals, magnesium, aluminum, brass, gold, silver, platinum, palladium, titanium; acrylic, rubber, Bakelite, vinyl, PVC, styrene, kevlar, PE, SMD component, films and foils, ceramic, nylon material in plastic, medical, mechanical, electronics, semiconductors, tool, metal, mold, watch, jewelry and mint Sector.

LMT2010 series fiber laser marking machine is widely used in automotive parts, hardware tool, food packaging, IC, PC components and accessories, watch, aerospace components, microelectronics, communications, industrial bearing, sanitary ware, glasses, home appliances, wire, cable, jewelry and other fields, e.g. graphics and text mark up.



Fiber laser Marking Machine: new desk style 10W  Metal Laser Marking Machine on Sale

Advantage:



Imported Germany fiber laser offers high quality laser beam, long laser life time
Robust hardware design improves reliability, higher MTBF expected.
High-speed scanning galvanometer and high performance servo motor guarantee high marking speed and high precision.
User-friendly controller and software make operation easier.
High electro-optical conversion efficiency, air cooling adopted for energy conservation and greener world, reduce power cost.



Fiber laser Marking Machine: new desk style 10W  Metal Laser Marking Machine on Sale

Specification:



Output Power:	20W
Laser Wavelength:	1064nm
Pulse Frequency:	<=100KHz
Marking Window:	110mm * 110 mm (4.33" * 4.33")
Minimal Marking Character Size:	0.15mm
Maximal Marking Depth:	0.01~0.50mm, depends on marking material
Minimal Marking Width:	0.01mm
Maximal Marking Speed:	10,000mm/s
Beam Quality	M2<1.5
Positioning Accuracy:	+/-0.02mm
Expected Laser MTBF:	100,000 hours
Cooling:	Air Cooled
Working Temperature:	0°C~40°C (32°F~104°F)
Power Consumption:	<=500W
