High Quality Compact Solar Vacuum Tube Solar Collector ,Model No:FP-GV2.05-01-A ( 2015*1015*76mm)

High Quality Compact Solar Vacuum Tube Solar Collector ,Model No:FP-GV2.05-01-A ( 2015*1015*76mm) thumbnail-1
High Quality Compact Solar Vacuum Tube Solar Collector ,Model No:FP-GV2.05-01-A ( 2015*1015*76mm) photo-1
US$ 180 - 280 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HS
Model Number:
FP-GV2.05-01-A ( 2015*1015*76mm)
Contact Supplier Request Quote Chat Now
Suzhou Sinoyin Solares Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name HS
Model Number FP-GV2.05-01-A ( 2015*1015*76mm)
Type Vacuum Solar Collector
Application Water Heater
Pipe Material Copper

High quality compact solar vacuum tube solar collector

Model No:FP-GV2.05-01-A ( 2015*1015*76mm)



Solar Collector Characteristics:



♦Germany imported blue titanium selectve coating,the most efficient absorber in the world



♦ Whole plate laser welding,to minimize the damage to absorption layer and copper tube



♦ 25 years lifespan



♦ Advanced processing technology and equipment,to guarantee products in high quality



Quality Assurance--Solar Collector Test



* Internal pressure for absorber       high quality compact solar vacuum tube solar collector ,Model No:FP-GV2.05-01-A ( 2015*1015*76mm)


* High temperature resistance


* Exposure test


* External thermal shock


* Internal thermal shock


* Rain penetration


* Mechanical load test


* Thermal performance


* Freeze resistance test



* Ice ball impact test

high quality compact solar vacuum tube solar collector ,Model No:FP-GV2.05-01-A ( 2015*1015*76mm)



















































How to produce the collector ?high quality compact solar vacuum tube solar collector ,Model No:FP-GV2.05-01-A ( 2015*1015*76mm)

 In-process
-Laser welder between absorber and copper tubing
-Process test with digital pressure meter at 1.2Mpa 5 minutes
-Automatic S type bending machine
-Automatic frame cutter
-Automatic frame assembly machine
-Automatic copper drilling machine
-Automatic plate leveling machine



Specifications:



Dimension L×W × H(mm):2015*1015*76mm



Gross Area(m²):2.05 m²



Absorber Area (m²): 1.82 m²



Number of covers:1



Cover material:Low iron tempered glass



Cover Thickness(mm):3.2mm



Cover Transmittance:>92%



Weight:41.5 Kg



Absorber:



Material:Aluminium board



Surface Treatment:Sputtering(Germany imported Blue titanium coating)



Absorptivity:95±2%



Emissivity: 5±2%



Construction Type:Grid type



Header Material:Copper TP2/CA1220



Header tube Size:Ø22mm x (thickness) 0.8 mm



Riser material: copper TP2/CA1220



Riser tuber size: Ø8mm x (thickness) 0.75mm



Working pressure: 0.75MPa



Test pressure: 1.2MPa, keeps 30 minutes



Whole Collector:



Maximum power, G = 1,000W/m² per collector: 1.352 kW



Thermal efficiency: 0.788



Heat loss coefficient (a1): 3.411 W/m².K



Heat loss coefficient (a2): 0.024 W/m².K



Maximum stagnation temperature for ambient conditions of 1,000W/m² and 30°C: 188.4°C



Thermal Insulation:



Insulation material: fiberglass



Insulation thickness: 35 ± 5mm



Insulation Density: 48 kg/cube



Casing:



Frame:Galvanized steel



Frame color: silver or black



Back plate: Galvanized steel



Sealing gasket: EPDM



Packing dimensions: 2,070 x 1,160 x 110mm



Water Tank Specifications:

Tank Capacity
S-S/Enamel

Solar Collector
FP-GV2.0

Electrical backup

person available

100L

2m²

1.5kw

2-3

200L

2m² or 4m²

1.5kw

3-4

300L

4m²

2.5KW

5-6

500L

8 m²

2.5KW

8-10



Certifications:Solar-keymark,SRCC,CE

 high quality compact solar vacuum tube solar collector ,Model No:FP-GV2.05-01-A ( 2015*1015*76mm)high quality compact solar vacuum tube solar collector ,Model No:FP-GV2.05-01-A ( 2015*1015*76mm)

About Sinoyin Solares



Sinoyin Solares is a famous solar factory located in Suzhou Industrial Park,it mainly specialize

in developping and producing high quality flat plate  solor collector and solar water heating

system for more than 6 years.

Why choose Sinoyin Solares?

1.S-type tube flat plate solar collector,have gotten the line patent in China.

no any welding on the  tube,no any leakage.

2.Whole plate laser welding,to minimize the damage to absorption layer.

3.The instant heat efficiency of the collector can up to 81.1%,much higher

than the 72% line standard,very rare in China.


4.The Solar Poducts has been selected into the official web of China government,it can



be verified on the internet.



How to contact us ?



Victoria



Suzhou Sinoyin Solares Co.,Ltd



Web:



Tel:86-0512-88876960/18915433725



Fax:86-0512-88876964



Products Showing Room:

high quality compact solar vacuum tube solar collector ,Model No:FP-GV2.05-01-A ( 2015*1015*76mm)



Sinoyin Solares in the Fair

high quality compact solar vacuum tube solar collector ,Model No:FP-GV2.05-01-A ( 2015*1015*76mm)
