2016 Stage Lighitng Beam Spot Wash 3 in 1 Moving Head Light

2016 Stage Lighitng Beam Spot Wash 3 in 1 Moving Head Light thumbnail-1
2016 Stage Lighitng Beam Spot Wash 3 in 1 Moving Head Light thumbnail-2
2016 Stage Lighitng Beam Spot Wash 3 in 1 Moving Head Light thumbnail-3
2016 Stage Lighitng Beam Spot Wash 3 in 1 Moving Head Light thumbnail-4
2016 Stage Lighitng Beam Spot Wash 3 in 1 Moving Head Light thumbnail-5
2016 Stage Lighitng Beam Spot Wash 3 in 1 Moving Head Light thumbnail-6
2016 Stage Lighitng Beam Spot Wash 3 in 1 Moving Head Light photo-1
2016 Stage Lighitng Beam Spot Wash 3 in 1 Moving Head Light photo-2
2016 Stage Lighitng Beam Spot Wash 3 in 1 Moving Head Light photo-3
2016 Stage Lighitng Beam Spot Wash 3 in 1 Moving Head Light photo-4
2016 Stage Lighitng Beam Spot Wash 3 in 1 Moving Head Light photo-5
2016 Stage Lighitng Beam Spot Wash 3 in 1 Moving Head Light photo-6
US$ 500 - 700 MOQ: 1 Piece
Key Specifications
Get Latest Price
Light Source:
Induction Lamps
Input Voltage(V):
AC 100-240V, 50/60HZ
Lamp Power(W):
470
Contact Supplier Request Quote Chat Now
Guangzhou Jin Zhi Hui Electronic Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Light Source Induction Lamps
Input Voltage(V) AC 100-240V, 50/60HZ
Lamp Power(W) 470
Lamp Luminous Flux(lm) 3355
Lamp Luminous Efficiency(lm/w) 563
Color Temperature(CCT) Warm White
Working Temperature(℃) -50, 50
Working Lifetime(Hour) 2000
IP Rating IP33
Certification CE, EMC
Emitting Color Changeable
Base Type GU5.3
Place of Origin Guangdong, China
Brand Name Toppest
Model Number 280w beam spot wash 3in1


2016 stage lighitng beam spot wash 3 in 1 moving head light


  1. Product Description



Technicial Specification



Lamp: OSRAM SIRIUS HRI 280W,10R

CT:9300K

Fuse: 250V, 6A

DMX channel: 16/24 channels

Color wheel: 13 colors+1 white

Gobo wheel I: 14 fixed gobos+1 open

Gobo wheel II: 9 rotating gobos+1 open

Prism: 8-facet circular prism and 6-facet linear prism, with focus, rotate, zoom, shaking function, adjustable speed

Movement: Pan 540 degree, Tilt 270 degree with Pan/Tilt Lock



DMX Channels



Model



Value

Function

Stand

Extend





1

1

0-255

Pan

2

0-255

Pan Fine

3

2

0-255

Tilt

4

0-255

Tilt Fine

5

3

0-255

Pan/Tilt Speed

6

4

0-19

Reserved

20-24

Eco mode(Lamp power 230w)

25-129

Reserved

130-139

Lamp On, reset

140-149

Pan/Tilt reset

150-159

Reserved

160-169

All motor reset

170-199

Reserved

200-209

Total reset

210-229

Reserved

230-239

Lamp Off

240-255

Reserved

7

5

0-8

Open/White

9-17

Deep Red

18-26

Deep Blue

27-35

Yellow

36-44

Green

45-53

Magenta

54-62

Azure

63-71

Red

72-80

Dark Green

81-89

Amber

90-98

Blue

99-107

Orange

108-116

CTO

117-127

Fluorescent Blue

128-129

White+Fluorescent Blue

130-134

Fluorescent Blue+CTO

135-138

CTO+Orange

139-143

Orange+Blue

144-147

Blue+Amber

148-152

Amber+Deep Green

153-157

Deep Green+Red

158-161

Red+Azure

162-166

Azure+Magenta

167-171

Magenta+Green

172-176

Green+Yellow

177-180

Yellow+Deep Blue

181-185

Deep Blue+Deep Red

186-189

Deep Red+White

190-220

Forwards rainbow effect from fast to slow

221-250

Forwards rainbow effect from slow to fast

251-255

Random colour selection by audio control

8

0-255

Colour wheel fine positioning

9

6

0-255

Speed of Rot.Gobo selection from max.to min.

10

7

0-3

Open/Hole

4-9

Gobo 1

10-15

Gobo 2

16-21

Gobo 3

22-27

Gobo 4

28-33

Gobo 5

34-39

Gobo 6

40-45

Gobo 7

46-51

Gobo 8

52-57

Gobo 9

58-63

Gobo 10

64-69

Beam reducer 1

70-75

Beam reducer 2

76-87

Beam reducer 3



Shaking gobos from slow to fast

88-95

Gobo 1

96-103

Gobo 2

104-111

Gobo 3

112-119

Gobo 4

120-127

Gobo 5

128-135

Gobo 6

136-143

Gobo 7

144-151

Gobo 8

152-159

Gobo 9

160-167

Gobo 10

168-175

Beam reducer 1

176-183

Beam reducer 2

184-199

Beam reducer 3

200-255

Forwards gobo wheel rotation from slow to fast

11

8

0-8

Open/Hole

9-17

Gobo 1

18-26

Gobo 2

27-35

Gobo 3

36-44

Gobo 4

45-53

Gobo 5

54-62

Gobo 6

63-71

Gobo 7

72-80

Gobo 8

81-89

Gobo 9



Shaking gobo from slow to fast

90-97

Gobo 1

98-106

Gobo 2

107-115

Gobo 3

116-124

Gobo 4

125-133

Gobo 5

134-142

Gobo 6

143-151

Gobo 7

152-160

Gobo 8

161-169

Gobo 9

170-179

Gobo 9 No rotation

180-217

Forwards gobo wheel rotation from fast to slow

218-255

Backwards gobo wheel rotation from slow to fast





12

9

0-127

Gobo indexing

128-177

Forwards gobo rotation from fast to slow

178-203

No rotation

204-255

Backwards gobo rotation from slow to fast

13

0-255

Rot.gobo indexing and rotaton Fine indexing

14

10

0-19

Open/Hole

20-75

6-facet linear rotating prism

76-255

8-facet circular rotating prism

15

11

0-127

Prism indexing

128-191

Forwards prism rotation from fast to slow

192-193

No rotation

194-255

Backwards prism rotation from slow to fast

16

12

0-64

Open

65-255

Frost from 0% to 100%

17

13

0-255

Zoom

18

0-255

Zoom fine

19

14

0-255

Focus

20

0-255

Focus fine

21

0-255

Reserved

22

15

0-31

Shutter close

32-63

Shutter open

64-95

Strobe-effect from slow to fast

96-127

Shutter open

128-143

Opening pulse in sequences from fast to slow

144-159

Closing pulse in sequences from slow to fast

160-191

Shutter open

192-223

Random strobe-effect from slow to fast

224-255

Shutter open

23

16

0-255

Dimmer intensity from 0% to 100%

24

0-255

Dimmer fine
